One is a modern GM ten-speed found behind everything from a 5.3L half-ton to a Camaro. The other is a Chrysler four-speed TorqueFlite descendant that spent its life behind 5.2L and 5.9L Magnum V8s in Rams, Dakotas, Durangos and Grand Cherokees. People searching this comparison are usually deciding which truck to buy, which platform to sink a rebuild into, or whether a swap makes any sense.

Parts for your 10L80

See all 10L80 rebuild kits

Get the parts for this repair
Shop 10L80 Parts →Shop 46RE Parts →

Here is the breakdown using published specs and manufacturer service data, plus the specific failure each unit is actually known for.

The short version

  • 46RE is the electronically-governed version of the Chrysler A518 four-speed. Simple, cheap to rebuild, hydraulically shifted, and repairable in a home garage with hand tools. Its weak points are wear items in the valve body and servo bores, not catastrophic hard parts.
  • 10L80 is a ten-speed with a 4.70:1 first gear, three overdrive ratios, and roughly double the torque rating. It drives better in every measurable way, but the failures it has are pressure-control failures that can put the truck into default mode at highway speed.
  • They share nothing. No case, no bellhousing, no valve body, no fluid, no controller. A 46RE-to-10L80 swap is a full driveline and electronics project, not a bolt-in.

Published specifications side by side

DieselHub publishes the full 10R80/10L80 ratio set: 1st 4.70:1, 2nd 2.99:1, 3rd 2.15:1, 4th 1.80:1, 5th 1.52:1, 6th 1.28:1, 7th 1.00:1, 8th 0.85:1, 9th 0.69:1, 10th 0.64:1, Reverse 4.87:1, with a nominal torque rating of about 800 N-m (roughly 590 lb-ft), a dry weight near 230 lbs, and a fluid fill of approximately 13 U.S. quarts of ULV ATF (DEXRON ULV on GM applications). Production runs 2017 to current.

The 46RE is the A518 gear train with electronic governor pressure control. Sonnax groups the family explicitly in its servo coverage: the flat-tip reverse servo plug covers the 40RH, 42RH/RE, 44RE (A500), 46RH/RE (A518), 36RH, 37RH (A727) and 30RH (A904), while the extended-tip version covers the 47RH/RE (A618) and 48RE. That four-speed set is the one DieselHub lists for its siblings the 47RE and 48RE: 1st 2.45:1, 2nd 1.45:1, 3rd 1.00:1, 4th 0.69:1, on ATF+4.

The difference that matters on the road: the 10L80's first gear is nearly twice as deep, and it has three overdrive ratios where the 46RE has one.

What actually fails on a 46RE

Almost every 46RE complaint traces back to bore wear in the valve body, not to broken hard parts. Sonnax's diagnosis for this family is that governor oil leaving the solenoid acts on the 1-2 and 2-3 bore plugs to stroke the shift valves, and bore wear there creates a loss of governor pressure that changes shift timing with operating temperature, producing a shuttle or late shift. The solenoid and transducer feedback loop is often too slow to compensate for that leak.

The symptom list Sonnax publishes for the 46RE reads like a used-truck buyer's checklist: 1-2 shuttle, 2-3 late, long 2-3 slide, poor kickdown, throttle buzz, delayed engagement, lockup shudder, no cooler flow in Park, and burnt bands. The fixes are specific parts, not a new transmission: governor bore plug kit 22771-14K, governor plugs 22771A-01 or 22771A-13, switch valve 22771-09, and the 46-47RHE-ZIP Zip Kit that seals losses across the main line, converter and throttle circuits.

The other classic 46RE failure is reverse. Sonnax notes that the OE aluminum reverse servo piston plugs wear and gall because the material is soft, and are prone to breaking at the spring seat area under the high stresses of Reverse. The symptoms they list are no Reverse, burnt Reverse band, and plug breakage. Their steel replacement is kit 22912-01K.

One identification trap before you order valve body parts: Sonnax's remanufactured valve body chart splits 46/47RE units by pressure sensor and pump inlet size. The early sensor ('99-and-earlier) has an oval-shaped electrical connector; the late sensor ('00-and-later) is plastic and rectangular. Get that wrong and the part will not work. Check the connector before you buy anything.

What actually fails on a 10L80

The 10L80 has one dominant failure and it is worth knowing before you buy a truck with one. Sonnax identifies severe side-load wear in the feed limit low valve, which limits line pressure feed to the default disable solenoid and control valves and also feeds the boost ball system for "A" and "B" clutch control. When that bore wears, pressure to the default disable solenoid drops and the vehicle can drop into default or power-loss mode. Sonnax states the valve can wear out in as little as 30,000 miles.

The symptom list for that one valve: momentary wheel lockup, sudden downshift to 2nd from high gear, harsh shifts, 5th gear only, a reduced propulsion message, code P0747, and burnt clutches. The drop-in fix is feed limit low valve kit 105740-54K. The feed limit high valve, which feeds "C" and "F" clutch control, gets 105740-58K or oversized 105740-60K. Bump shifts, no 2nd, neutral shifts and slide shifts point instead at the CDF Drum Saver Kit 129910-01K.

This is not hypothetical. NHTSA recall 24V797000 covers certain 2020-2022 Chevrolet Silverado and GMC Sierra 1500/2500/3500 plus 2021 Escalade, Tahoe, Suburban, Yukon and Yukon XL models with diesel engines, where "the transmission control valve may fail and cause the rear wheels to lock-up." The remedy was new transmission control module software plus special coverage for transmissions the software flags as having a defective control valve. Follow-up campaign 26V083000 (GM number N252516560) covers vehicles repaired incorrectly under the first recall, with owner letters mailed March 6, 2026. Run the VIN before you buy.

Which one to choose

If you want the better transmission to drive and tow with, it is the 10L80, and it is not close: nearly 590 lb-ft of nominal rating against a light-duty gas four-speed, three overdrives, and a 4.70:1 launch gear.

If you want the cheaper transmission to own long-term, it is the 46RE. It is fully rebuildable on a bench with common tools, its failures are inexpensive valve and servo parts rather than electronics, and there is no software, no TCM programming, and no dealer-only calibration in the loop. For a 1996-2003 Ram, Dakota, Durango or 5.9L Grand Cherokee you plan to keep, a proper 46RE valve body and servo refresh is one of the best-value repairs there is.

Do not swap one for the other. Nothing is shared - case, converter, mount, crossmember, cooler line, shifter, controller - and the 10L80 needs a full GM electronic architecture to shift at all.

The fix: which parts, and why

On a 46RE, the jobs that solve the most complaints are pan-off jobs. A filter and fluid service with a fresh governor solenoid and transducer is the entry point, and it is where you first see whether the pan is full of clutch material.

46RE transmission filter with sensor, pan gasket, governor solenoid, pressure transducer and springs
46RE Transmission Filter with Sensor - filter, pan gasket, governor pressure solenoid and transducer in one kit.

For a 1998-1999 truck specifically, match the year range: the 46RE Transmission Filter 98-99 is the correct fit, and the full transmission filters collection covers the rest of the RE family. On the GM side, an intermittent speed signal on a 10L80 is often the 10L80 output speed sensor rather than anything internal, and the rest of the unit's service parts live in 10L80 transmission parts. If your 10L80 diagnosis points at burnt clutches from a feed limit valve failure, the clutch packs collection is where that repair starts.

Replace while you are in there

46RE, pan off: filter and pan gasket, governor pressure solenoid and transducer, governor bore plugs, valve body separator plate gaskets, reverse servo piston plug and seals, and the front and rear band adjustment checked to spec. If the pan has clutch material in it, stop and pull the unit instead.

10L80, valve body out: feed limit low and high valves, LPC signal damper piston, valve body gaskets and seals, pan filter, and a full ULV fluid exchange. Sonnax also sells the pump vane (124533) and the 6mm valve body checkball (10000-08, 0.250" imidized plastic) if a rebuild turns up a missing or damaged one.

Cost and effort, realistically

A 46RE fluid, filter and governor solenoid service is a 2-3 hour driveway job for anyone comfortable dropping a pan. A valve body pull with a Zip Kit and governor bore plugs adds roughly 3-4 hours and needs care with checkball placement. A full 46RE rebuild runs about 8-12 hours of shop labor.

The 10L80 is a different level of effort. The valve body is dense, the fluid level check is a temperature-dependent procedure rather than a dipstick reading, and the unit is heavy at roughly 230 lbs. Budget 4-6 hours of shop labor for a valve body service and treat internal work as a specialist job. Recall work under 24V797 is performed free of charge by GM dealers.

FAQ

Is the 10L80 stronger than the 46RE?
Yes, by a wide margin on paper. DieselHub lists the 10L80 at a nominal roughly 590 lb-ft, and the 46RE is a light-duty gas-engine four-speed from the A518 family. Strength is not the 10L80's problem; pressure-control valve wear is.

My 46RE shifts late when it is hot but fine when cold. What is that?
That pattern matches the governor pressure circuit. Sonnax attributes temperature-dependent shift timing changes in this family to bore wear at the governor plugs causing pressure loss the solenoid and transducer cannot compensate for. Governor bore plug kit 22771-14K is the published fix.

Should I be worried about the 10L80 wheel-lockup recall?
Check the VIN. NHTSA campaign 24V797000 and the follow-up 26V083000 both address a transmission control valve failure that can lock the rear wheels. Both remedies are free at a dealer.
