You checked the transmission fluid on your Titan, Xterra, Pathfinder or Frontier and it came out pink, milky, or the color of a strawberry milkshake. Or the truck shifts hard, flares between gears, takes two seconds to engage Drive, and the shop just quoted a replacement transmission. Both complaints belong to the same 5-speed unit, and in a large share of cases to the same root cause: the automatic transmission fluid cooler Nissan built into the radiator.

This is the RE5R05A, a Jatco 5-speed longitudinal automatic also cataloged as the JR507E/JR509E and, in Subaru form, the TG5C/TG5D "5EAT." Per the Jatco 5R05 reference, it ran from 2002 to 2019 behind rear-drive and 4x4 applications including the Nissan Titan (2003-2015), Xterra (2005-2015), Pathfinder R51 (2005-2012) and Armada (2004-2016), plus the Infiniti Q45, G35 and FX35, the Kia Sorento and Borrego, and Subaru 3.0R/3.6R models. Sonnax notes the unit first appeared in the 4.5L Infiniti Q45 in 2002.

Symptom 1: Pink or milky fluid, the radiator cooler failure

This is the failure that generated a federal defect petition. In NHTSA's closing resume for petition DP12-004, the agency describes the problem as "Co-mingled ATF/Coolant due to radiator failure results in transmission failure," covering MY 2005-2010 Nissan Frontier, Xterra and Pathfinder over a population of 857,432 vehicles. NHTSA logged 2,505 complaints, of which 638 involved a potential hazard (inability to maintain speed, no motive power, or engine stall) and 1,867 were customer-satisfaction issues including repair cost, shudder and shake, and engine overheating. The petition was opened June 11, 2012 and denied on October 22, 2016, so there is no recall: this repair is on the owner.

The rebuilder-side data is just as blunt. In RE5R05A Facts and Observations, Sonnax TASC Force member Jeff Parlee writes that "about one half of the cores we receive have water intrusion from failed coolers in the radiator," and advises replacing the cooler even when it has not yet failed, because it is only a matter of time before one does and damages a fresh transmission.

Why it kills the transmission: ethylene glycol attacks the adhesive bonding friction material to the clutch plates and swells the rubber seals and bonded pistons. The debris then loads the filter and circulates through the valve body and solenoids. A coolant-contaminated RE5R05A is never a fluid-flush job.

Symptom 2: Harsh shifts, flare, delayed or no engagement, valve body bore wear

If the fluid is clean and red but the unit shifts badly, the pilot valve bores are the first place to look. Sonnax's "A" or "B" Pilot Valve Kit 63741-13K documentation lists the exact complaint set: delayed engagement, erratic shifts, flare upshifts with clutch distress, delayed or no Forward, delayed or no Reverse, and premature or firm TCC apply.

The mechanism explains why two trucks with the same worn casting behave differently. Per Sonnax, wear at the inboard end of the bore causes excessive feed pressure, which floods the solenoids, reduces their reaction time, and produces harsh shifting and high line pressure. Wear at the outboard spool lets fluid leak into the sump port and reduces solenoid modulator pressure, which hits engagements and the boost oil for line pressure rise hardest.

Which circuits go bad depends on which bore is worn. Sonnax states that pilot valve "A" feeds the line pressure modulating solenoid and the TCC solenoid, while pilot valve "B" feeds the direct and input clutch, front brake band, low coast brake, and high and low/Reverse solenoids. An "A" bore problem therefore reads as line pressure and lockup trouble; a "B" bore problem reads as shift and engagement trouble.

Diagnosis, in order

  1. Pull the dipstick and look at the fluid before anything else. Pink, tan, milky or foamy fluid means coolant intrusion. Stop there, and do not attempt a solenoid or valve body repair on that unit.
  2. Pressure-test the radiator's ATF cooler circuit if the fluid is questionable. Cross-contamination runs both directions, so also check the coolant reservoir for an oily film.
  3. Scan for codes and check solenoid resistance. This is where the RE5R05A traps people. Sonnax notes Infiniti used a low-resistance (10-15 ohm) low coast solenoid until August 2005, then switched to the high-resistance (20-40 ohm) solenoid Nissan had always used. Bosch, Nachi and Mitsubishi all built these, and Sonnax says different-manufacture solenoids interchange only if their resistance matches. Measure before you order.
  4. Identify your valve body design. Sonnax documents three versions: the first has two neutral-to-reverse accumulators on the lower body behind the manual valve and an empty valve bore under the low coast solenoid; the second has the same two accumulators plus a reverse brake pressure control valve in that bore; the third has one large neutral-to-reverse accumulator. Sonnax is explicit that these should not be interchanged.
  5. Vacuum-test the pilot valve bores. Sonnax's test procedure for 63741-13K calls for a wet air test or a vacuum test at the indicated location, with the vacuum test required to hold a minimum of 18 in-Hg. Leakage below that means the bore is worn.
  6. Check the cooler bypass valve bore. Sonnax warns that not all RE5R05A valve bodies even have a cooler bypass valve, and where the bore is empty, the separator plate is closed off above it. Do not diagnose a missing valve as a lost valve.

The fix: which parts, and why

For a coolant-contaminated unit, the only honest repair is a full teardown and overhaul. Every friction, every bonded piston, every seal, the filter, and the torque converter come out, and the radiator or an external cooler goes in at the same time. A RE5R05A Transmission Rebuild Kit covers the frictions, steels, gaskets and seals in one box so you are not chasing individual part numbers mid-build.

RE5R05A transmission rebuild kit with frictions, steels, gaskets and seals
RE5R05A rebuild kit, the correct starting point once coolant has been in the fluid.

For a clean-fluid unit with shift complaints, the repair is targeted. On its RE5R05A unit page, Sonnax lists the correction by symptom: Pilot Valve Kit 63741-13K for the engagement and shift-quality complaints above; Oversized Pressure Regulator & Boost Valve Kit 63741-01K for delayed Forward, harsh Reverse, erratic line pressure, harsh 2-3 and Reverse slip; Oversized Cooler Bypass Valve Kit 63741-07K for overheated fluid, overheated converter and premature lockup; and TCC Control Plunger Valve Kit 63741-25K for lockup shudder and TCC cycling, which Sonnax says fits third- and fourth-design valve bodies containing the .282 in. diameter OE plunger valve. Sonnax also catalogs solenoid 63421 for the line pressure/TCC/front brake circuit against line pressure instability and TCC apply concerns, and 63425 for the direct/input/high and low reverse clutch circuit against shift concerns.

If the scan data points at solenoids rather than bores, a complete RE5R05A Shift Solenoid Kit from our transmission solenoids collection replaces the set at once, which is the sane move on a unit this age. Replacing one solenoid and leaving four originals in place usually just buys you a second teardown.

Replace while you are in there

  • RE5R05A transmission filter and pan gasket, mandatory on any contaminated unit. See the full transmission filters collection for the variant matching your pan.
  • Torque converter. A contaminated converter cannot be flushed clean and will re-contaminate a fresh build.
  • Radiator or a dedicated external ATF cooler, per Sonnax's advice above.
  • All bonded pistons and lip seals, because glycol swells them.
  • Full solenoid set if the unit is past 150,000 miles and already apart.
  • Fluid: OEM spec is Nissan Matic J, superseded in the US by Matic S in 2009 per the Jatco 5R05 reference. Do not substitute a generic ATF.

Cost and effort framing

A valve body repair using Sonnax kits is a bench job: pan down, valve body out, disassemble, ream the worn bores with the specified tooling (F-63741-TL13 for the pilot valves, F-63741-TL for the pressure regulator, F-63741-TL7 for the cooler bypass, all in the VB-FIX fixture), reassemble, reinstall. Figure roughly 4 to 6 hours of shop labor for a tech who already owns the tooling, plus fluid. The reaming step is what separates it from a driveway repair.

A full overhaul after coolant contamination is a different animal: transmission out, complete teardown, hard-part inspection, plus a converter and a cooler. That is realistically 12 to 18 hours of labor on a 4x4 truck, and one missed contaminated component takes the whole build with it. The deciding question is simple. Was there ever coolant in the fluid? If yes, overhaul. If no, repair the bores.

FAQ

Was there ever a recall for the Nissan radiator and transmission cooler problem?
No. NHTSA opened defect petition DP12-004 on June 11, 2012 and denied it on October 22, 2016, citing the allocation of agency resources and the likelihood that further investigation would find an unreasonable safety risk. No safety recall was mandated, so the repair is the owner's responsibility.

Can I just flush the transmission if the fluid is only slightly pink?
No. By the time the fluid discolors, glycol has already been through the clutch packs and seals. Sonnax's core data, roughly half of the RE5R05A cores it receives showing water intrusion from failed radiator coolers, reflects units that arrived as complete failures rather than as flush candidates.

Are all RE5R05A valve bodies the same?
No, and this is the most common parts mistake on this unit. Sonnax documents three distinct designs and states plainly that they should not be interchanged. Verify your design and measure solenoid resistance before ordering.

For a broader model overview including the 7-speed that replaced it, see our Nissan Titan and Frontier transmission guide covering the RE5R05A and RE7R01A, or browse all transmission rebuild kits.
