700R4 vs AW4: Differences, Strength, and Which One to Choose

If you are standing over a Jeep XJ with a tired automatic, or planning a GM V8 swap into a Cherokee, the decision usually comes down to two four-speed overdrive automatics: the GM 700R4 and the Aisin-Warner AW4. They look similar on paper -- four speeds, lockup converter, overdrive top gear -- but they are controlled in completely different ways, they fail in completely different ways, and the parts you need to keep each one alive are not interchangeable. Here is what actually separates them.

The short answer

Keep the AW4 if the engine is stock or mildly built and you want a transmission that shifts itself intelligently with almost no setup. Go 700R4 if you are putting a Chevrolet-pattern engine in front of it, want a steeper first gear for towing or off-road crawling, or want a transmission you can build to serious power without touching a computer. The AW4 is the easier unit to live with. The 700R4 is the more capable unit to build.

What each transmission actually is

The 700R4 was introduced by GM in 1982 as a fuel-economy answer to the TH350, and its headline features were a 30 percent overdrive fourth gear and an unusually low first gear. Per Novak Conversions, that first gear is 3.06:1 -- steeper than almost anything else in its class -- which is exactly why it stayed popular for off-road and heavy-vehicle use long after GM moved on. Sonnax notes the unit went through an auxiliary valve body revision in 1987, and that the 700R4 and the 4L60 are the same transmission under two names, with GM changing the official designation in 1989 (Novak places the rename at 1990 -- published sources differ by a model year here). Most models ran through 1993 before the electronically controlled 4L60-E took over.

The AW4 is an Aisin-Warner design, and it is essentially the same family as the Toyota A340 used in rear-drive Toyota applications. Novak documents its Jeep run as 1987-2001 in the XJ Cherokee and MJ Comanche, almost always behind the AMC 4.0L inline-six, with limited use in the 1993 ZJ Grand Cherokee. Internally it carries the model designations #30-43LE for two-wheel drive and #40-30LE for four-wheel drive.

Side-by-side

Note that the two length figures are published differently -- Novak lists the 700R4 number as main case length and the AW4 number as overall length -- so do not treat that two-inch gap as a drop-in comparison. Measure your own tunnel and driveshaft before committing.

The real difference: how each one decides when to shift

This is where most people get it wrong, and it drives every other decision.

The 700R4 is hydraulic. Sonnax describes it as having a cast iron valve body with a throttle cable and mechanical governor determining shift points. The TV (throttle valve) cable is not a kickdown cable. It sets line pressure in proportion to throttle position, and if it is loose, mis-routed, or set at the wrong length, the transmission does not simply shift late -- it runs on low line pressure and cooks its clutches. That is the single most common way a freshly installed 700R4 dies.

The AW4 is electronic, but only partly. The factory ATSG service booklet for the AW-4 states the unit uses "a valve body with electric solenoids and a transmission computer unit (TCU)," with signal sequence determined by vehicle speed and throttle position. Solenoid number two controls the overdrive elements and solenoid number three controls converter lockup. But the same document also says plainly that "cables are used for shifting and throttle pressure control." In other words, the AW4 still has a line pressure cable. The TCU picks the gear; the cable still sets the pressure that applies it.

That distinction matters for diagnosis. On an AW4 with high or low line pressure, the factory test procedure calls for a gauge rated to at least 300 psi and gives these targets: 53-61 psi in Drive at curb idle, 161-196 psi in Drive at wide open throttle, 73-87 psi in Reverse at idle, and 223-273 psi in Reverse at wide open throttle. If pressures fall outside those windows, ATSG's instruction is to adjust the line pressure cable and retest before condemning anything internal. Factory stall speed is 2100-2400 rpm in both Drive and Reverse.

Where each one breaks

700R4: the 3-4 clutch. Sonnax calls burnt 3-4 clutch packs "notoriously common" in the 4L60 family and identifies low line pressure and leaks of third gear oil as the root cause of most 3-4 slipping. The 3-4 circuit is long and shares oil with the D4, forward clutch, second, second clutch, and third accumulator circuits, so small leaks at several junctions add up to enough pressure loss to slip. Two specific culprits: the steel throttle valve plunger wears the aluminum sleeve it rides in, letting throttle valve feed oil leak past and killing line rise; and the weak OE 3-4 backing plate flexes under application, trapping heat unevenly in the clutch pack. Sonnax also gives a hard test spec for the input housing checkball -- it must hold 25 in-Hg of vacuum, and anything below that is an impermissible leak.

AW4: heat and parasitic loss. Novak is blunt about this one. The AW4 has "a tendency to generate excessive amounts of heat" and is "known for unnecessarily consuming more engine power than some other automatics." They also flag irregular-feeling shift points and unreliable torque converter lockup engagement, and classify the unit as light to medium duty requiring proper cooling to reach decent service life. Practically: an AW4 that is shifting oddly or refusing to lock up is far more often a solenoid, a TCU input, or a heat-cooked fluid problem than a hard parts problem. Our AW4 common failures and rebuild guide walks the diagnostic order in more detail.

The fix: which parts each choice commits you to

If you keep the AW4, the highest-value repair is almost always the solenoid set, because all three live on the valve body and come out with the pan. Solenoids one and two select the four gears in combination and solenoid three handles lockup, so a single failed unit can present as a missing gear or a converter that never locks.

If you go 700R4, budget for a proper rebuild rather than a parts-swap. Because the failure mode is pressure-driven, replacing only the burnt frictions leaves the cause in place. A full 700R4 Master Transmission Rebuild Kit for 1987-1992 covers the frictions, steels, gaskets, seals, filter, and bushings in one box. Pair it with a 700R4 shift kit to address valve body calibration while the pan is off, and browse the rest of the 700R4 parts catalog for the servo, band, and boost valve pieces Sonnax recommends for durability builds.

Replace while you are in there

• 700R4: TV cable and its bracket geometry, intermediate band, second gear servo, pump boost valve, 3-4 backing plate, filter and pan gasket, and both stator support bushings. Sonnax specifically calls the stator support bushings vital and frequently overlooked.
• AW4: all three solenoids as a set, filter and pan gasket, line pressure cable adjustment, and an auxiliary cooler. Given Novak's heat warning, the cooler is not optional on a worked XJ.
• Both: rear extension housing seal, converter, and fresh fluid of the correct specification -- Mercon or Dexron II for the AW4 per factory data.

Cost and effort

An AW4 solenoid job is a driveway repair: drop the pan, unbolt the valve body solenoids, reinstall, refill, and adjust. Call it two to four hours for a competent DIYer with the vehicle on stands, and it is one of the few transmission repairs that does not require pulling the unit.

A 700R4 rebuild is a different scale of job -- transmission out, full teardown, and a bench assembly that requires endplay measurement and clutch clearance checks. Plan on a weekend minimum with the right tools, or eight to twelve hours of shop labor. If the 700R4 is going into a Jeep as a swap, add adapter and driveshaft work on top: Novak offers an AMC engine adapter kit (#437AMC) and transfer case adapters for the NP231, NP242, and Dana 300, and they explicitly advise against the 700R4 in short-wheelbase Jeeps like the CJ-5 due to powertrain length and driveshaft angle.

FAQ

Is the AW4 the same as a Toyota A340? They are the same family. Novak notes a comparable version called the A340 was used in Toyota rear-wheel-drive applications, which is why many AW4 service parts are cataloged under A340 part numbers.

How much power can a 700R4 take? Sonnax states the 700R4 is still very capable in many applications up to about 750 horsepower when built with upgraded pump, input housing, shell, servo, and band components. That is a built unit, not a stock core.

Can I put a 700R4 behind a 4.0L inline-six? Not directly. The 700R4 uses the Chevrolet 90-degree bellhousing pattern, so it requires Novak's #437AMC adapter kit to mate to AMC engines. Most people choosing the 700R4 route are already swapping to a Chevrolet-pattern engine, which makes the transmission choice follow the engine choice rather than the other way around.

Why does my AW4 shift fine but never lock up? Lockup is controlled by valve body solenoid number three through the lockup relay valve, per factory service data, and lockup only occurs in specific ranges -- second gear in the 1-2 position, third in the 3 position, and third and fourth in Drive. Confirm you are in a range that commands lockup before condemning the solenoid.

Sources

• The Novak Guide to the Aisin-Warner AW4 Transmission -- Novak Conversions
• The Novak Guide to the GM TH700R4 / 4L60 & Early 4L60-E Automatic Transmission -- Novak Conversions
• 700-R4 (4L60) Performance Transmission Build Guide -- Gregg Nader, Sonnax
• All Over the Map: Attacking 4L60/E Burnt 3-4 Clutches with Confidence -- Brian Wing, Sonnax
• Jeep AW-4 Transmission Service Information -- ATSG (Automatic Transmission Service Group), with Chrysler Corporation illustrations
