P0744 is the generic OBD-II code for "Torque Converter Clutch Circuit Intermittent." On a 4L60E it sits in the same family as P0740 through P0743, but the word "intermittent" is the important part: the PCM saw the torque converter clutch circuit behave correctly some of the time and incorrectly the rest of the time. That points the diagnosis at connectors, harness chafe, a solenoid coil that opens up when hot, or debris that makes the solenoid stick unpredictably, rather than at a converter that has failed outright. This article covers how the code sets, the 4L60E's TCC hardware, the diagnosis order, and the parts that actually fix it.

Parts for your 4L60E

4L60E Master Rebuild Kit - Frictions & Steels, Gaskets & Seals, Filter, Shift Kit, Servo, Solenoids, Bushings (7-Piece) — $233.99

See all 4L60E rebuild kits

Get the parts for this repair
Shop 4L60E Parts →

What P0744 means on a 4L60E

Per OBD-Codes, the transmission control module monitors the torque converter clutch solenoid circuit during operation and sets P0744 when it detects an intermittent malfunction in that circuit. On the 4L60E the PCM is the controller. The "circuit" is the wiring from the PCM through the case connector to the TCC solenoids, and back through the solenoid coil.

Transmission Repair Cost Guide describes it as the PCM not being in full control of the converter clutch. Symptoms range from an intermittent check engine light and a small fuel economy loss (OBD-Codes) to erratic shifting, shudder or vibration, stalling at a stop, and overheating if the converter is slipping under load. On a 4L60E a common real-world complaint is the converter dropping in and out of lockup on the highway, felt as a slight RPM flutter with no throttle change.

The 4L60E TCC hardware

The 4L60E uses two solenoids for lockup. The TCC enable solenoid is a simple on/off solenoid that sends pressurized fluid to the converter clutch; the TCC PWM solenoid is pulse-width modulated to control how quickly the clutch applies. Per the CPT 4L60E TCC overview, the TCC solenoid is located inside the pan on the front passenger side of the transmission near the valve body. CPT lists the related codes as P0740, P0741, P0742, P0743, P0744 and P1870, and notes the main symptom of a failed TCC solenoid is the converter not locking, which shows up as higher RPM under highway load. Downstream of the solenoids, the TCC regulator apply valve in the valve body meters the apply oil; a worn valve bore makes lockup apply erratic even when the electrical side is perfect.

Diagnosis order

  1. Fluid level and condition. Transmission Repair Cost Guide states that dirty ATF can keep the TCC solenoid from working properly, and that the most common diagnostic mistake is replacing the converter when the real fault is a solenoid or contaminated fluid. Check the level hot in Park and look at the color and smell.
  2. Read all codes and freeze frame. If P0744 comes with P0740 or P0743 (electrical), the wiring or coil is the target. If it comes with P0741 or P1870 (performance or slip), the converter clutch itself is slipping and the intermittent is a symptom of a hydraulic problem.
  3. Inspect the harness and case connector. OBD-Codes puts the wiring check first: look for chafed harness, loose or corroded pins at the round case connector, and an internal harness rubbed through against the valve body. Wiggle-test the connector with the scan tool watching TCC command and slip.
  4. Test the solenoid. OBD-Codes recommends measuring coil resistance against spec, testing voltage on the feed side, and tapping the solenoid while testing to expose an intermittent open. A coil that reads correct cold and opens when hot is a classic P0744 cause; test it again after a highway drive.
  5. Verify the PCM command. With a scan tool, watch the TCC duty cycle command versus actual slip RPM. If the command is steady and slip is erratic, the fault is hydraulic (solenoid sticking, regulator valve bore, converter). If the command itself drops out, the problem is upstream (brake switch, wiring, PCM).
  6. Pull the pan. Metal in the pan or on the magnet means the converter clutch lining or another component is shedding material, and the intermittent lockup is debris jamming the solenoid or valve.

Causes, most likely first

  • Damaged or corroded wiring and connectors between the PCM and the case connector, or the internal harness inside the pan (OBD-Codes, Transmission Repair Cost Guide).
  • Failing TCC solenoid, either an intermittent coil or a plunger sticking on debris. Every source lists it.
  • Dirty or low fluid that lets the solenoid hang up.
  • Worn TCC regulator or apply valve bore in the valve body, which makes apply pressure unstable.
  • Worn converter clutch that grabs and releases under load.
  • Brake switch or PCM input problems that cancel the lockup command intermittently. Rare, and diagnosed last after the wiring and solenoid are proven.

The fix

If the wiring is damaged, repair it and re-pin the connector. If the fluid is dirty, service it with a new filter. If the solenoid fails the resistance or tap test, or if the fault is intermittent with no wiring damage found, replace the TCC solenoid; it is inside the pan, so the fluid and filter come with the job anyway. The 4L60E TCC Lock-Up Solenoid 1993-2000 is the on/off enable solenoid, and the 4L60E Lockup PWM Solenoid 24227747 is the pulse-width solenoid. Replace both if either is suspect; they are inexpensive and the labor is identical. The rest of the family is in the solenoid collection.

4L60E TCC Lock-Up Solenoid 1993-2000
The part behind most 4L60E P0744 repairs: 4L60E TCC Lock-Up Solenoid 1993-2000.

If the electrical side checks out and lockup is still erratic, address the valve body. The 4L60E TCC Regulator Valve and Isolator Sleeve Kit restores a worn regulator bore; the rest of the valve body repair options are in the valve body collection. If metal is in the pan and slip persists after the solenoid and valve body work, the converter is the remaining item.

Replace while you're in there

  • Both TCC solenoids (enable and PWM), since the pan is off.
  • Internal wiring harness if any pin is green or any wire is chafed.
  • Filter and pan gasket.
  • Shift solenoids on a high-mileage unit; they are the same age and the same labor.
  • TCC regulator apply valve kit if the bore shows wear on a vacuum test.

Cost and effort framing

Most 4L60E P0744 repairs are a pan-down job: fluid, filter, one or two solenoids and a connector repair, well within reach of anyone who has done a fluid and filter service. The expensive path is replacing the converter first without proving the circuit, which is the mistake the sources warn about. Do the wiring and solenoid tests, then the valve body, and leave the converter for last. For the related codes, see 4L60E TCC solenoid replacement: symptoms, diagnosis and fix and 4L60E P0742 TCC stuck on: causes and fix.

Frequently Asked Questions

Can I drive a 4L60E with P0744?

Usually yes for a short time. The main risks are lower fuel economy and heat if the converter clutch slips under load. If you feel shudder or the transmission runs hot, stop driving and diagnose it.

Is P0744 the TCC solenoid or the torque converter?

On a 4L60E it is most often the wiring, connector or TCC solenoid. The converter is the last item to suspect, and only after the circuit tests clean and the pan shows metal.

Which 4L60E solenoid controls lockup?

Two of them: the on/off TCC enable solenoid and the TCC PWM solenoid that controls apply rate. Both are inside the pan on the valve body, and both should be replaced together when one is suspect.
