Two GM automatics, fifty-three years apart. The Turbo Hydra-Matic 400 went into production in 1964 and stayed in GM cars and trucks through 1990. The 10L80 ten-speed arrived for 2017 and is still in production. Both are the strong rear-wheel-drive automatic of their era, and if you are building a truck, a muscle car, or a swap chassis, you have to pick one. Here are the real ratios, torque numbers, failure modes, and labor costs.

Parts for your 10L80

See all 10L80 rebuild kits

Get the parts for this repair
Shop 10L80 Parts →Shop TH400 Parts →

The Numbers Side by Side

Per DieselHub's TH400 specification page, the TH400 is a three-speed with 2.48:1 first, 1.48:1 second, 1.00:1 third and 2.07:1 reverse. It measures 24-3/8 inches long, weighs roughly 150 lbs with fluid, uses a 32-spline input shaft, runs DEXRON automatic transmission fluid, and carries a nominal input torque rating of about 450 lb-ft. The case is aluminum with an integrated one-piece bellhousing.

DieselHub's 10L80/10R80 page lists the ten-speed as 4.70, 2.99, 2.15, 1.80, 1.52, 1.28, 1.00, 0.85, 0.69 and 0.64 with a 4.87:1 reverse. It weighs roughly 230 lbs, holds approximately 13 U.S. quarts, uses ULV automatic transmission fluid (DEXRON ULV on the GM side), and carries a nominal input torque rating of about 800 N-m, roughly 590 lb-ft. Production runs 2017 to current.

Three things jump out of those two lists.

First gear. The TH400 launches on 2.48:1. The 10L80 launches on 4.70:1, nearly double the multiplication. That is why a modern truck with a shallow rear axle ratio still pulls hard off the line: the transmission is doing work the axle used to do.

Overdrive. The TH400 has none. As Novak's TH400 guide notes, third gear is 1.00:1 and that is the end of the box; overdrive did not arrive in this family until the 4L80-E. The 10L80 has four overdrive ratios, the tallest being 0.64:1. On the highway that is the entire difference between a screaming three-speed and a modern cruise rpm.

Torque capacity. The ten-speed is rated roughly 140 lb-ft higher from the factory. That surprises people who grew up hearing the TH400 called bulletproof. Both numbers are conservative OE ratings, and both units are commonly built well past them.

Where the TH400 Still Wins

Simplicity. There is no computer, no shift solenoid pack, no CAN bus handshake. A TH400 will run behind a carbureted big block with nothing but a modulator line and a shift linkage. Novak documents native bellhousing patterns for Chevrolet 90-degree small and big block engines and for the Buick/Olds/Pontiac/Cadillac pattern on the appropriate case version, plus adapter requirements for AMC engines and the Jeep sizing ring (#J5352374) that goes between the converter and the AMC crankshaft.

Weight. At roughly 150 lbs versus 230 lbs, the TH400 is about 80 lbs lighter. In a drag car or a light chassis, that matters.

Parts availability and rebuild difficulty. A TH400 is a weekend rebuild for a competent home mechanic. The hard parts have been produced continuously for sixty years. Its known weak point is well understood: Sonnax documents that on high-mileage TH400 and TH425 units the hardened steel pressure regulator valve oscillates in the cast-iron pump bore until the bore wears, letting balance line pressure leak past the valve and exhaust to the sump. The result is poor line pressure control and high cooler pressure, which takes out converters, friction elements, and in bad cases crankshafts. That is a known fix with a known kit, not a mystery.

Where the 10L80 Wins

Everything about how the vehicle drives. The 4.70:1 first gives launch authority that a 2.48:1 first cannot approach without a numerically steep axle, and the 0.64:1 tenth gives cruise rpm that a three-speed cannot approach without a numerically shallow one. You do not have to choose between the two.

Hard-part strength is also genuinely higher. If you are rebuilding one, the rotating hardware is where the money goes. The 10L80 planetary set shows what the ten-speed carries internally compared to a three-speed's single gearset.

10L80 planetary set with thrust washer and ring gear
10L80 planetary set: the hardware that makes ten ratios possible.

The 10L80's Real Weak Points

Do not buy the ten-speed thinking it is trouble-free. Sonnax's rebuilders list a consistent set of failures in their 10-speed valve body article: CDF drum sleeve movement, cylinder clutch container failure (the "stove pipe" failure), main shaft plugs loosening, overheating from incorrect ATF level, speed sensor issues, and incorrect assembly on the rebuild. They also note that impregnated separator-plate filters come loose and cause valves to stick, and that these units use casting-integrated direct-acting solenoids (CIDAS) retained by clips, which is why a 10-speed has no movement at all when it is unplugged from the electrical source.

Then there is the recall. Sonnax's breakdown of GM Safety Recall N242480630, issued March 2025 and covering the 10L1000 and Gen. 2 10L60, 10L80 and 10L90, explains the mechanism: the feed limit low valve wears, control pressure to the default disable solenoid drops, and the default enable and default select valves lose the pressure they need to hold position. Because those valves route line pressure to the clutches through the exhaust circuit when the default disable solenoid is off, the failure shows up as a momentary wheel lock-up at higher speed or a drop back into second gear. Sonnax notes the feed limit low valve has a history of high wear at low vehicle mileage.

Translation: a used 10L80 out of a wrecked truck is not a plug-and-play win. Check the recall status and plan on the valve body.

Which One to Choose

Choose the TH400 if the vehicle is pre-computer, you want no electronics in the driveline, you are drag racing where a three-speed's simplicity and 80 lbs of savings pay off, or you are doing a 4WD swap where transfer case adaptation matters. Novak lists TH400 compatibility with Dana 18, Dana 20, Dana 300 and New Process transfer cases, and notes that a 2WD unit needs an output shaft change to go 4WD.

Choose the 10L80 if the vehicle is 2017-or-later and already has one, or you are doing a modern LS/LT swap into a chassis where you can support the wiring and controller. The driveability gap is not close.

What most people actually want is the middle ground: a 4L80E, which is a TH400 with an overdrive and electronic control added. We covered that trade-off directly in TH400 vs 4L80E: which one for your build. And if you are already inside the ten-speed family, 10L80 vs 10L90 covers the sibling comparison.

Cost and Effort, Honestly

A TH400 rebuild is a one-day job for an experienced builder and a long weekend for a first-timer. The unit comes apart with hand tools, the pump is the only fussy part, and no scan tool is required to put it back in service. Budget shop time in the four-to-six hour range for removal and reinstallation on a body-on-frame truck.

A 10L80 rebuild is not a first-timer job. It is a multi-clutch unit with tight endplay specs, a valve body that requires bore inspection, and a fill procedure that depends on ULV fluid at the correct temperature. Sonnax specifically flags overheating from incorrect ATF level as a repeat failure cause. Removal and reinstallation alone typically runs longer than a TH400 because of the electrical and cooler plumbing.

Whichever you build, the clutch packs and solenoids are where you should not economize. For a TH400 refresh, the TH400 steel clutch plate kit covers the steels while you are in there.

Replace While You Are In There

  • TH400: pressure regulator valve and bore, per the Sonnax wear pattern above; front pump seal; intermediate sprag; complete steel and friction set; modulator; filter; and the converter if line pressure was ever low.
  • 10L80: feed limit low valve and main pressure regulator valve; separator plate, checked for a loose impregnated filter; CDF drum hardware; filter; speed sensors; and the full clutch set. Confirm the recall was performed before you reuse a valve body.

FAQ

Is a TH400 stronger than a 10L80? Not on paper. The TH400's nominal input torque rating is about 450 lb-ft; the 10L80's is about 590 lb-ft. The TH400's reputation comes from how simple and how buildable it is, not from a higher factory rating.

Can I swap a 10L80 into a classic car? Mechanically it is a large, heavy unit, and it will not move at all without its electronics. The solenoids only produce clutch pressure with current applied, so you need a controller and harness solution. A TH400 needs neither.

Is the 10L80 the same as the Ford 10R80? The hard parts are shared. DieselHub notes that GM and Ford publish slightly different gear ratios only because of rounding preferences, and that the electronic controls differ between the two manufacturers.
