You just finished the job. The transmission is in, the bolts are tight, and the first time the engine cranks you hear a grinding rattle from the bellhousing, or the unit builds no pressure at all and will not move. On that kind of comeback, usually nobody missed a clutch pack. The torque converter was not fully seated when the transmission was pulled up to the block.
Shop rebuild kits and parts by transmission
This is one of the few failures in this trade that is entirely preventable, and it takes about five minutes to check. Here is how to know the converter is in, what the measurement should be, and what it costs you when it is not.
Symptoms of a converter that was not fully seated
A converter engages in three places at once: the pilot in the end of the crankshaft, the drive lugs on the pump gear, and the splines on the input and stator shafts. Miss any one and the damage shows up immediately or within a few hundred miles.
- Grinding or knocking from the bellhousing on first start. The converter hub is chewing the pump gear or the pump body.
- No pressure, no movement. The pump gear was never driven, or it was destroyed in the first few seconds of run time.
- The bellhousing would not pull flush by hand. This is the tell before you ever start it. If there was a gap and you closed it with the bolts, you already loaded the pump.
- Front pump seal leak and a scored converter hub a short time after the job.
- Vibration under load from a converter running off the crankshaft centerline.
One noise does not belong on that list. A sound that is silent in Park and Neutral, present in every drive range forward and reverse, and louder under load points to an internal converter bearing, not a seating problem. Sonnax technical specialist Ed Lee documents that pattern across three teardowns in Torque Converter Forensics and notes that overall height and endplay should both be checked before a converter is condemned.
The measurement: stab depth
Stab depth is how you prove engagement instead of guessing at it. Per the Sonnax tech article on 4L60-E 300mm converter pump gear failures:
- Bolt the transmission to the engine.
- Push the converter into the pump until the converter drive slot bottoms on the lugs of the pump gear.
- Measure the gap between the flexplate and the mounting pads of the converter.
Sonnax gives that gap a hard window: a minimum of .125 inch to avoid damaging or destroying the pump, and no more than .250 inch to prevent pump gear failure. Too little gap and the converter is being jammed into the pump. Too much and the impeller drive hub is not far enough into the pump gear to drive it reliably.
ATRA's GEARS magazine gives the same working window from the R&R side, stating that on most units the clearance between the flexplate and the mounting pads should be between 1/8 inch and 1/4 inch. Sonnax's R&R checklist article narrows the typical range further, to 1/8 inch to 3/16 inch once the bellhousing is seated against the engine.
If you only have the converter on the bench, Sonnax describes a rough check: measure from the witness marks in the lug contact area of the impeller hub to the bottom of the drive slot. In their documented case that measured about .310 inch, matching the stab depth measured in the vehicle.
Overall height matters too, because it is what puts the pads where they belong. Per the same Sonnax article, the OE overall height spec for GM 300mm converters is 6.550 inches, with the Corvette unit the exception at 6.254 to 6.275 inches. The 2002-2003 Bravada, Envoy and TrailBlazer 4.2L "VJCX" converter carried a 6.500 inch OE spec but most measured only about 6.450 inches, which is why those units kept coming back with pump gear failures.
The two checks that matter before the transmission goes up
The hand test. Sonnax's rule is blunt and it is the single most useful thing in this article: the bellhousing should push flush against the engine by hand, and the torque converter should still move if it is correctly seated. Never use the bellhousing-to-engine bolts to draw the transmission in. If it will not go by hand, the converter is hung up on a shaft or the pump gear, and pulling it in with bolts is what breaks pumps.
The dowel pins. GEARS says to check that the rear face of the block is clean and free of paint or burrs and that the alignment dowels are in place and protrude far enough to index the transmission. Sonnax is specific about the consequences of skipping that: missing dowel pins can cause pump bushing failure, converter hub failure, flexplate damage, pump seal leaks and possible pump damage. More on that in our writeup on bellhousing dowel pins and why alignment is critical.
The fix, and what to replace while you are in there
If the stab depth is out of spec, Sonnax lists three approaches and endorses only one. Shimming the gap between the flexplate and the mounting pad works only if the converter's overall height is 6.500 to 6.550 inches, and you must confirm you still have sufficient pilot engagement in the crankshaft afterward; on a short converter around 6.450 inches, the shim pulls the pilot out of the crank and you lose that support entirely. Adding a thicker bearing race without machining the original mating surface makes the converter taller but adds .060 inch of internal clearance, which Sonnax notes makes the converter less efficient, increases stall and raises operating temperature. Their recommended fix is a taller impeller hub, which corrects overall height while keeping internal clearance correct.
If the pump already ate itself, you are into the front of the unit anyway. While it is apart:
- Front pump seal, pump bushing, and the pump body and gears if there is any scoring
- The converter itself if the hub is scored, along with a full 4L60E master rebuild kit or the equivalent for your unit, since metal from a pump failure travels
- Flexplate, checked for cracks and ring gear tooth damage per the Sonnax checklist, and the crankshaft spacer on the Ford applications that use one
- Converter bolts, verified by threading them in first. Sonnax says the head should touch the pad finger tight; GEARS warns that bolts that are too long may damage the reaction surface for the lockup clutch
- The cooler and lines. Sonnax calls for a minimum cooler flow of one quart of fluid in 20 seconds on 5/16 inch lines, noting most transmissions produce a quart in 10 seconds when working correctly
See our full bellhousing leak, front pump seal and converter hub diagnosis guide if you are chasing the leak side of this.
Cost and effort
The check itself is close to free: a depth gauge or a straightedge and a feeler, and about five minutes with the transmission bolted up before the converter bolts go in. Getting it wrong means pulling the driveshaft, exhaust, crossmember and transmission back out to replace a pump you already paid for, plus a converter, fluid, a cooler flush, and the labor to do the entire R&R a second time. Difficulty on the measurement is beginner level. Difficulty on the comeback is the whole job again.
Two more habits from the Sonnax checklist prevent the same class of failure: torque the flexplate-to-crankshaft bolts in the proper sequence or a star pattern rather than with an impact gun, which can stretch and break them, and pull the converter to the flexplate evenly instead of hitting the first bolt with an impact to close the gap. GEARS adds that modern units have high-capacity pumps and small fill tubes or ports, making it possible to run the pump dry and damage the pump and converter on initial startup.
FAQ
What gap should I see between the converter pads and the flexplate? Between 1/8 inch and 1/4 inch on most units per GEARS, with Sonnax specifying a minimum of .125 inch and a maximum of .250 inch on the 4L60-E 300mm application and a typical range of 1/8 to 3/16 inch.
Can I just shim the converter to fix a wide gap? Only within limits. Sonnax says shimming is viable when overall height is 6.500 to 6.550 inches, but on a converter around 6.450 inches the shim pulls the pilot out of the crankshaft. Confirm pilot engagement before you trust a shim.
The converter pilot is loose in the crank. Is that normal? No. Sonnax notes a loose fit indicates a missing sleeve or ring, and without it the converter is not spinning on the crankshaft centerline, which risks vibration, flexplate damage, pump damage and front seal leaks.
If the converter is already damaged, start with our torque converter failure diagnosis guide.
