The front pump is the heart of a TH400. Every clutch, band and the torque converter depend on the oil it moves, so when the pump wears, the whole transmission suffers - a whine that will not go away, slipping under load, or in the worst case no movement at all. The good news is that the TH400 pump is simple, and most worn pumps can be rebuilt on the bench if the body is still in spec. This guide covers the symptoms, what actually wears out, and how to decide between rebuilding and replacing, based on published rebuilder and manufacturer tech information.

TH400 Remanufactured Pump Assembly 6-Bolt
The part for this fix
TH400 Remanufactured Pump Assembly 6-Bolt
$369.99 · In stock
Shop This Part →

How the TH400 Pump Works

The TH400 uses a gear-type pump: an inner drive gear and an outer driven gear separated by a crescent cast into the pump body. The inner gear is driven by tangs on the torque converter hub, so the pump turns whenever the engine runs. As Cliff Ruggles explains in his TH400 rebuild guide, the pump is made in two halves - the pump body and the pump cover (which carries the stator shaft) - and it must be split to reach the gears, bushing and seal.

Symptoms of a Failing TH400 Pump

  • Whine in every range - per the ASE A2 study guide, a worn or faulty pump whines in all gears, including Park and Neutral.
  • Slipping - RepairPal notes a weak pump may not make enough pressure to apply the clutches and bands, which shows up as slipping.
  • Low pressure at low engine speed - CK Performance's TH400 oil pump notes report reduced pump pressure and volume below 2500 RPM when gear face clearance is too loose.
  • No movement in any gear - RepairPal states a totally failed pump will keep the vehicle from moving.
  • Fluid leak at the front of the transmission - a failed front pump seal leaks at the bellhousing.

Diagnosis: Rule Out the Easy Stuff First

  1. Check fluid level and condition before condemning any hard part.
  2. Suspect the filter before the pump. The ASE A2 study guide warns that a restricted or clogged filter makes the same whining noise as a faulty pump - make sure the filter is good before replacing the pump.
  3. Separate pump noise from converter noise. The same guide notes a torque converter is loudest in gear with the wheels held stationary, and the noise disappears in Park or Neutral. A whine that stays in Park and Neutral points back toward the pump. Our guide on transmission whine in Park and Neutral walks through this in more detail.
  4. Measure line pressure. A gauge reading compared against the factory specification for your application tells you whether the pump is keeping up before you pull the transmission.
  5. Find the leak source. A leak at the front of the transmission can point to the front pump seal - see our bellhousing leak diagnosis guide.

What Causes TH400 Pump Failure

Worn pump bushing

Sonnax explains that worn babbitt pump bushings in the TH400 let the converter hub and inner pump gear move off-center, which damages the pump gears and the crescent in the pump housing. CK Performance lists a recommended bushing-to-converter-hub clearance of .001 to .004 inch and recommends replacing the bushing at the first overhaul. If the bushing was loose in its bore or has spun, the body must be replaced.

Gear pocket and crescent wear

CK Performance notes the side wall of the gear pocket acts as a bearing journal for the outer gear, riding on a fluid film. Scoring on the pocket wall, the pocket face, or either side of the crescent reduces pump efficiency. Their rule is simple: if you can feel the wear with a fingernail, replace the body.

Gear clearance out of spec

Per the same notes, gear-to-pocket clearance should be .002 to .006 inch, and inner gear to crescent .002 to .0075 inch. They warn to check even new aftermarket gear sets, since most they measured came in at .008 to .014 inch. GM revised the gear face-to-pump body clearance several times over the TH400's production, with the final revision at .0007 to .0026 inch; CK Performance prefers .0007 to .0015 inch because looser clearance costs pressure and volume below 2500 RPM. Production gears measure about .7265 to .7275 inch thick, while 1964-1966 fixed pitch units with casting number 1358649 use .625 inch gears.

Warped pump body or cover

Both faces are checked with a precision straightedge. CK Performance states a .001 inch feeler gauge should not fit under the straightedge; if it does, the face is warped and must be resurfaced or replaced to keep hydraulic circuits from cross-leaking. Resurfacing lowers the pocket depth, which then calls for undersize gears (.721, .723 and .725 inch sets are available).

Stator shaft and bushings

CK Performance notes early stator shafts were not induction hardened and are prone to spline wear; later shafts have hardened splines and are black in color. The front and rear stator shaft bushings should allow .0005 to .0035 inch of turbine shaft clearance. Sonnax offers a heat-treated chromoly TH400 stator support shaft with induction-hardened splines for heavy-duty builds.

Converter installation damage

According to CK Performance, improper converter-to-flexplate clearance usually damages the pump gear where it meets the converter drive tangs. Ruggles adds that pulling the transmission up to the engine with the bellhousing bolts before the converter is fully seated can damage the oil pump.

The Fix: Rebuild vs Replace

  • Rebuild if the pocket, crescent and bushing bore pass inspection and the faces are flat. A rebuild typically means new gears (sized to the pocket), bushing, front seal, gasket and seal rings.
  • Replace the pump body if there is wear you can feel with a fingernail in the pocket or on the crescent, the bushing spun in its bore, or the face is out of flat and cannot be resurfaced. For 1973-and-later 6-bolt units, our TH400 remanufactured pump assembly (6-bolt) is a complete bolt-in replacement.
  • Consider a billet pump for high-horsepower builds. Transmission Digest has covered performance TH400 pumps built with billet steel gears, a bolt-in stator tube and steel wear plates for each pump half.
TH400 front pump rebuild kit with gear set, front seal, bushing, gasket and O-ring
TH400 front pump rebuild kit with gears, seal, bushing, gasket and O-ring

For a bench rebuild, start with the TH400 front pump rebuild kit with gears, or upgrade the bushing with the PTFE-lined Sonnax 34034T-01 pump bushing. For a performance build, see the TH400 billet front oil pump. Browse everything else in TH400 transmission parts or our full transmission pumps collection.

Reassembly Tips That Prevent a Comeback

  • Align the pump halves. Ruggles notes the two halves must be aligned or the pump will not fit back into the case. Use a TH400 pump alignment band (a large hose clamp band works in a pinch), then torque the cover-to-body bolts - CK Performance lists 200 inch-pounds.
  • Pre-lube the gears. Packing the gear pocket with assembly lube prevents damage on a dry first start.
  • Spin-check on a converter. Set the assembled pump on a TH400 converter and verify the gears turn freely.
  • Match the bolt pattern. CK Performance notes 1971-1972 late pumps use eight pump-to-case bolts, while 1973 and later use six - important if you replace the pump.

Replace While You Are In There

  • Front pump seal and pump-to-case gasket - always new.
  • Pump cover seal rings - 1975 and later units use scarf-cut Teflon rings.
  • Selective thrust washer - it sets front endplay between the pump and forward drum. For heavy-duty builds, the Sonnax 34211-01K pump thrust bearing kit replaces the washer with a .126 inch bearing and shims in .005 inch steps; Sonnax notes pump machining is required in most cases.
  • Stator shaft bushings - if turbine shaft clearance is out of spec.

Cost and Effort

The pump itself is not the expensive part of this job - the labor is. The transmission has to come out and the pump has to be pulled from the case, so a full inspection with a straightedge, feeler gauges and a micrometer is worth the extra hour. If the pump failed from a worn bushing, check the converter hub too, and if the unit has been slow to engage, confirm the rest of the hydraulic system while it is apart.

Frequently Asked Questions

Can a TH400 pump be rebuilt instead of replaced?

Yes, in most cases. If the gear pocket, crescent and bushing bore show no wear you can feel with a fingernail and both faces are flat, new gears, a bushing, seal and gasket restore the pump. Replace the body if it fails those checks.

What is the TH400 pump gear clearance?

GM's final published gear face-to-body clearance was .0007 to .0026 inch. CK Performance recommends .0007 to .0015 inch for best low-speed pressure and volume, with .002 to .006 inch between the outer gear and pocket wall.

Why does my TH400 whine in Park and Neutral?

A pump whine is present in all ranges, including Park and Neutral, but a clogged filter makes the same noise. Check the filter first.
