It shows up the same way on almost every one of these cars. You pull away from a stop light, the engine loads up around 20 to 30 mph, and the whole car buzzes like you are driving over rumble strips. Let off and it clears. Roll back to a stop and you may feel a second shudder just before the car settles. Sometimes the light comes on with P2762 or P2757, sometimes the scan tool only hands you a generic transmission code and you are left guessing.

TR580 Lock-Up Solenoid
The part for this fix
TR580 Lock-Up Solenoid
$63.99 · In stock
Shop This Part →

That is the classic torque converter lock-up complaint on a Subaru Lineartronic CVT, and on the TR580 it is one of the few CVT problems with a genuinely repairable root cause. This is what is actually failing, how to prove it before you spend a dime, and which parts do the job.

First: confirm you have a TR580

Subaru ran two Lineartronic families side by side, and they are not serviced the same way. Per Gears Magazine (ATRA), the identification tag sits above the starter. A TR690 is the first-generation unit and its valve body lives in the bottom pan. A TR580 is the second-generation unit and its valve body sits on top of the transmission, under a sound shield and cover plate.

That layout is why the TR580 job is realistic in a driveway and the TR690 job is not. On the TR580 you pull the top sound shield and cover plate, then remove the twelve valve body-to-case bolts to reach the solenoids.

What is actually failing

Two separate problems produce the same shudder, and they have different fixes.

1. The lock-up duty solenoid goes open circuit when it gets hot. Gears documents three normally closed solenoids in these valve bodies: Lock-Up Duty, Primary Up, and Primary Down. All three read roughly 12 ohms at 68°F, and all three are interchangeable between generations. The failure is thermal, which is exactly why it drives people crazy: the car is fine cold and shudders once it is warm, and the solenoid measures perfectly on a cold bench. Gears calls out P2763 as the open-circuit code you will see when it finally sets.

2. The valve sleeve in the control valve body wears. Subaru itself acknowledged this. Service Bulletin 16-156-25, dated 09/30/25 (NHTSA ID 11023523), announces a design change to the CVT Control Valve Body incorporating an enhanced valve sleeve to improve durability. The bulletin lists the symptoms it is meant to prevent: P2757 (torque converter clutch pressure control), P2762 (lock-up duty solenoid malfunction), shudder while accelerating from a stop, and shudder while decelerating to a stop. Applicability runs 2012-23 Impreza and Crosstrek, 2014-23 Forester 2.5, and 2013-19 Legacy and Outback 2.5L. The updated part number is 31825AA055 for TR580-equipped vehicles.

An electrical fault and a hydraulic wear fault land in the same circuit and feel identical from the driver seat.

Diagnosis, in order

  1. Scan and record freeze frame. P2762 or P2757 points straight at the lock-up circuit. A bare generic transmission code with no subcode does not rule it out, it just means the TCM has not caught the fault at the moment it happens.
  2. Reproduce the complaint warm. Drive it until the CVT is at operating temperature, then hold light throttle through the 20 to 40 mph band where lock-up applies. Cold-only testing will pass a failing solenoid.
  3. Watch TCC slip on the scan tool. If the shudder tracks with commanded lock-up and the slip number will not settle, you are in the right circuit.
  4. Ohm the solenoid, then heat it. Roughly 12 ohms at 68°F is the target per Gears. Their test is the important one: heat the solenoid to about 200°F with a heat gun, and you will usually see the circuit open when it gets hot if the solenoid is the problem. A solenoid that opens hot is condemned.
  5. Look at the fluid. Dark, varnished, or burnt fluid means debris has been circulating through the lock-up circuit, and that changes the repair plan below.

The fix

Subaru's own answer is to replace the entire control valve body, because it does not sell the individual solenoids separately. Gears notes the same thing, and points out the practical alternative the trade actually uses: replace the failed lock-up solenoid, since the solenoids are interchangeable and the mounting is straightforward once the valve body is off.

TR580 lock-up solenoid for Subaru Lineartronic CVT
TR580 Lock-Up Solenoid — the part that fixes the hot-shudder complaint when the solenoid opens under heat.

If the solenoid tests good cold and hot, and the fluid is clean, the shudder is hydraulic and you are into the valve body itself, which is where the enhanced-sleeve design change in 16-156-25 applies. If the fluid is dark and the car has high miles, treat it as a contamination job rather than a single-part job.

Replace while you are in there

The cover plate is off and the fluid is out. These are the items worth doing in the same visit:

  • Filter. Subaru has been chasing debris in this exact circuit since the beginning. Bulletin 16-89-13 (12/18/2013) added an in-line CVT fluid filter, part number 31835AA040, specifically to reduce contamination entering the lock-up circuit on TR690 units, along with a machined case passage and a smaller ported valve body surface to retain it. It is a one-time-use item that must be replaced if removed, and it cannot be retrofitted to earlier cases. Fit a fresh TR580 transmission filter while the unit is open.
  • The other two solenoids. They are the same part and the same age. If one opened from heat cycling, the others have lived the same life.
  • Fluid, and the correct fluid. ENEOS, a CVT fluid supplier for these applications, is blunt about it: never use regular automatic transmission fluid in a Subaru CVT, because the wrong fluid can cause severe damage to the transmission.
  • Pan gaskets and seals. Cheap insurance on a job you do not want to open twice.

If the fluid came out dark and metallic, or the unit already has a chain or pulley noise, stop replacing individual parts. That is a teardown, and a full TR580 overhaul rebuild kit is the honest starting point. Browse the rest of the transmission solenoid catalog if you are matching parts for a different unit.

Effort and difficulty

On a TR580 the solenoid replacement is a top-side, in-vehicle job: sound shield, cover plate, twelve valve body bolts, solenoid swap, reassemble, refill and level the fluid to temperature. A competent DIYer with a lift and a scan tool that reads CVT fluid temperature should plan on a solid afternoon. The fill procedure is temperature-dependent and unforgiving, and it is where most driveway jobs go wrong. Full valve body replacement is the same access with a higher parts cost and no more labor.

One thing worth checking before you buy anything: Subaru extended CVT coverage on a large block of older cars. Bulletin 16-107-17R extended the powertrain warranty on the CVT from five years or 60,000 miles to ten years or 100,000 miles for 2010-2015 Legacy and Outback, 2012-2015 Impreza, 2013-2015 Crosstrek, 2014-2015 Forester, and 2015 WRX. Subaru states the change was not in response to any specific condition. Most of those cars are now outside the extended term, but it is a two-minute check.

FAQ

Is a lock-up shudder the same thing as CVT chain failure?
No. A lock-up shudder is a torque converter clutch problem and it appears in a narrow speed band under light load. Chain and pulley damage shows up as noise, slipping under load across the whole range, and metal in the fluid. The diagnostic steps above are meant to separate the two before you commit to a teardown.

Why does my solenoid pass a resistance test but the car still shudders?
Because the failure is thermal. The Gears procedure is to heat the solenoid to roughly 200°F before testing, since the circuit typically opens only when hot. A cold bench test on a heat-failed solenoid reads normal.

Can I just replace the one solenoid instead of the whole valve body?
Subaru does not sell them individually, which is why the dealer path is a complete control valve body. Gears documents that the Lock-Up Duty, Primary Up, and Primary Down solenoids are interchangeable, which is what makes individual solenoid replacement a workable repair. If the bore or sleeve is worn rather than the solenoid, the valve body is the correct fix, and that is precisely what bulletin 16-156-25 addresses.

For the hydraulic side of this diagnosis, see our walkthrough on how to vacuum test a valve body and find bore wear.
