A ring and pinion that whines after a regear is almost never a bad gear set. It is usually a bad setup: the pinion is the wrong distance from the ring gear, or backlash is off. Both are set with shims, and both show up in the contact pattern you paint onto the teeth. Here is how to read that pattern, what backlash and pinion depth each control, and which parts you need on the bench to adjust them.

Shop Install Kits With Shims and Marking Compound

Browse the full bearings and install kits collection and ring and pinion gear sets. Check the fitment text on each listing before you order.

Yukon Gear master overhaul kit for Ford 8.8 differential with bearings and shim kit
A master overhaul kit includes the shims you need to move pinion depth and carrier position.

Two Settings, Two Jobs

Pinion depth is how far the pinion sits from the ring gear centerline. It sets the contact pattern. Backlash is how far the ring gear can rotate back and forth with the pinion held still. It is set by the ring gear's (carrier's) position. As The Ranger Station's Ford 8.8 backlash guide puts it, pinion shims establish the mesh pattern, not the backlash; carrier shims fine-tune backlash once the pattern is right.

A new gear set also carries a depth reference. Richmond's install guidance says each set is marked on the pinion face with a "checking distance," and that the pinion should be installed within 0.002 inch of the marked figure. The same guide gives 0.007 to 0.009 inch backlash for that specific street gear set. Backlash targets vary by gear set, so use the number from your own instructions, not another set's.

How to Paint and Roll the Pattern

  1. Clean the ring gear teeth. Use genuine gear marking compound; Yukon's install instructions say anything else, such as machinist's dye, will not give a clear indication of tooth contact. Thin it with a little oil if needed so it is a smooth paste, not runny.
  2. Apply a moderate amount to three or four teeth in several places around the ring gear.
  3. Rotate the ring gear four or five times around the pinion in both directions, per Yukon's guidance.
  4. Read the drive side (convex) and coast side (concave) patterns, and compare them to the pattern chart in your gear set's instructions.

Reading Pinion Depth From the Pattern

Yukon's guide describes the ideal new-set pattern as centered from face (top of the tooth) to flank (root):

  • Pattern near the flank (too deep): the pinion is too close to the ring gear.
  • Pattern near the face (too shallow): the pinion is too far from the ring gear.
  • Heel and toe position: Yukon says housing influences keep the pattern from being perfectly centered from heel to toe, so concentrate on face-to-flank position and not on the heel-to-toe placement.
  • Used gear sets: concentrate on the coast side only and pay little attention to the drive side.

What moves what, again per Yukon: moving the pinion closer to the ring gear moves the drive pattern deeper (toward the flank) and slightly toward the toe, while the coast pattern moves deeper and slightly toward the heel. Moving the pinion farther away moves the drive pattern toward the face and slightly toward the heel, and the coast pattern toward the face and slightly toward the toe.

Adjusting Without Chasing Your Tail

  • Change pinion shims in meaningful steps. Yukon calls 0.005 to 0.015 inch a large change and 0.002 to 0.004 inch a small one: make large changes until the pattern is close, then small ones. Richmond adds that pinion shims usually must move in 0.003 inch increments before you notice a pattern change.
  • Re-check backlash after every shim change. Pinion depth and ring position interact, so do not assume the number you set earlier still holds.
  • Use the carrier shim rule. Per Yukon, backlash changes about 0.007 inch for every 0.010 inch the carrier moves: move the carrier 0.010 inch toward the pinion to cut backlash by 0.007 inch, or away to add 0.007 inch. Take shim thickness off one side and add the same amount to the other to keep preload constant.
  • Measure ring gear runout. The Ranger Station guide says runout on the ring gear face should be 0.003 inch or less; use a dial indicator on a magnetic base.
  • Finish with pinion bearing preload. Once depth and backlash are in range, Yukon says to remove the carrier and establish the final pinion bearing preload (Richmond's guidance uses a new crush collar or preload shim pack for this).

When You Need a Different Kit

If the pattern will not come in, you may simply be out of shim thickness. Master kits carry a full shim range; see master install kit vs bearing kit. A whine you cannot trace to setup may be worn parts: read differential whine symptoms. After the pattern is right, follow the 500 mile break-in procedure. Doing a Ford 8.8? See Ford 8.8 ratios and install tips.

Effort and Cost Framing

This is the slow part of a regear. Expect several rounds of pull the carrier, change shims, reinstall, paint and roll. Doing it with the right shim kit and marking compound on hand keeps it to a day; discovering you are short a shim thickness halfway through does not.

Frequently Asked Questions

What does backlash control on a ring and pinion?

Backlash is the lash between the teeth and is set by moving the ring gear (carrier) toward or away from the pinion. Pinion depth, set with pinion shims, controls where the contact pattern lands.

How do I know if the pinion is too deep?

Per Yukon, a pattern closer to the flank means the pinion is too close to the ring gear; a pattern closer to the face means it is too far away.

How many times should I rotate the ring gear to read the pattern?

Yukon's instructions say to rotate the ring gear four or five times around the pinion in each direction after applying marking compound.
