A vibration that shows up around 50 or 60 mph and gets worse as you speed up is one of the most common driveline complaints. It can come from the driveshaft itself (balance, a bent tube, worn joints), from the angles the U-joints run at, or from something that only feels like the driveshaft. This guide shows how to tell the difference and which parts fix it.

Shop Driveshafts and Driveline Parts

If your shaft is bent, dented, out of balance or worn out, a replacement is the clean fix. These are in our store; the make, model, years and transmission in each title must match your vehicle.

Browse the full driveshafts collection or drivetrain components.

Driveshaft Shop aluminum 1-piece driveshaft
Aluminum one-piece driveshaft, Camaro 2010-2015 V8 6-speed automatic.

Step One: Is It Angle-Related or Dynamic?

4XShaft separates driveshaft vibration into two types (4XShaft diagnosing drive shaft vibrations):

  • Angle-related: felt at lower speeds, roughly 0 to 40 mph, worse on heavy throttle and load, felt as a shudder, and it improves when you lift off the throttle or shift to neutral. It often starts right after a lift or lowering is installed.
  • Dynamic: felt at about 50 mph and above and gets worse with speed. It is not helped, or is made worse, by releasing the throttle. If it gets worse over time, it points to loose components or an aged shaft.

A highway-speed vibration is therefore usually a dynamic (balance or condition) problem, although a high-mileage shaft can have both.

Common Causes

  • Driveshaft imbalance. Imbalance forces climb with speed: the force at 2,000 rpm becomes four times as large at 4,000 rpm and nine times as large at 6,000 rpm (RCN Magazine). A lost balance weight, mud or undercoating on the shaft, or a dent will do it.
  • Worn or tight U-joints and loose components. 4XShaft lists imbalanced shafts, loose front or rear components, misaligned transfer case or pinion yokes and bent output shafts as typical causes.
  • U-joint working angles. Mark Williams states the best operating angle is about 0.5 degrees, with the maximum for racing use not more than 2 degrees, and with the centerlines parallel within 0.5 degrees. If the centerlines are not parallel, the U-joints turn at uneven speeds and cause a vibration that feels like an unbalanced shaft (Mark Williams driveshaft tech).
  • Critical speed. A long shaft run at high rpm can reach its natural frequency, which causes severe vibration. The same source says critical speed depends on length, diameter and the weight-to-stiffness ratio of the material, and that switching from steel to aluminum can raise critical speed by roughly 12 percent (RCN Magazine).
  • Bad tire balance or wheel runout. These are not driveline parts, but they can feel similar. See the checks below.

Diagnosis Steps

  1. Park the truck and shake the shaft. 4XShaft's check: grab the shaft by hand and look and listen for movement or knocking at the U-joints and slip yoke.
  2. Check the shaft. Look for dents, missing balance weights and a bent tube. RCN lists a tube runout limit of 0.020 inch or less over the full length for a balanced shaft.
  3. Check engine speed at 60 mph. 4XShaft notes typical highway engine speed is 2,500 to 2,800 rpm at 60 mph, and above 3,000 rpm suggests very low gearing, which spins the shaft faster.
  4. Measure working angles after any lift, lowering, or engine/transmission change. The goal is parallel centerlines, with small equal angles at both ends.
  5. Rule out tires and wheels. If the vibration is in the steering wheel rather than the seat, balance tires before replacing driveline parts.

Fixes

  • Replace worn U-joints and yokes if there is play in the shake test.
  • Re-balance or replace the shaft if it is bent, dented or has lost weights. Rebuilding with a straight, balanced shaft is cleaner than chasing it.
  • Correct the angles with shims or by adjusting the pinion angle after suspension changes.
  • Use a stiffer or lighter shaft if a long or high-rpm setup keeps hitting critical speed. See our guide to aluminum vs steel vs carbon driveshafts.

RCN quotes balance standards of 0.20 oz-inch or less for a finished shaft, and U-joint phasing within 0.1 degrees end to end (Dynotech Engineering figures). That is why a quality shaft is usually a bigger improvement than any adjustment to a damaged one.

Replace While You Are In There

  • U-joints on both ends, plus the slip yoke if it is worn.
  • Transmission tail-housing seal and bushing, and the pinion seal if it leaks.
  • Center support bearing on two-piece shafts.
  • If the pinion feels loose, check the differential. Our differential whine guide covers the signs.

Pulling and refitting a driveshaft is usually a one-to-two-hour job with hand tools; mark the shaft and yoke before removal so the phasing returns to where it was. Axle upgrades go hand in hand with driveline work, so see chromoly vs stock axle shafts as well.

Frequently Asked Questions

Why does my driveshaft vibrate only at highway speed?

Imbalance force rises with speed (four times at double the rpm, per the figures RCN quotes), so a small imbalance may be invisible at low speed and obvious at 60 mph or more.

Can bad U-joints cause a vibration at speed?

Yes. Worn joints and joints running at the wrong angles both cause vibrations; angle-related ones tend to appear at lower speeds under load.

Does a lift or lowering cause driveshaft vibration?

It can. 4XShaft notes angle-related vibrations often begin right after a lift is installed because working angles change.
