A manual C6 or C7 Corvette gives plenty of warning before the clutch goes. The tach flares on a hard 2-3 shift, the pedal engages higher and higher, or the car chatters pulling away from a light. Replacing the clutch on these cars is not like a front-engine pickup. The transmission sits at the back of the car, joined to the engine by a torque tube, so the whole rear driveline has to come down to reach the clutch. Because the labor is the expensive part, picking the right kit the first time matters. This guide covers the symptoms, how the job is done, and the published specs of the kits that fit 2005-2013 C6 and 2014-2019 C7 Corvettes.

Get the parts for this repair
Shop C6 Corvette Clutch Kit →Shop Clutch Kits →

Signs Your C6 or C7 Clutch Is Done

  • Slip under load: RPM climbs in 3rd or 4th at full throttle without a matching gain in speed. Tunes, headers and cams make this show up sooner.
  • High engagement point: the clutch only grabs near the top of pedal travel, a sign the disc is worn thin.
  • Chatter on takeoff: often a glazed or hot-spotted flywheel surface, not just the disc.
  • Burnt smell after launches, track sessions or a long stop-and-go crawl.
  • Soft pedal, poor release or fluid loss: this points to the hydraulic slave cylinder and release bearing assembly rather than the friction parts. It is the reason most Corvette kits include a new slave.

Quick Diagnosis Before You Buy

  1. Check the clutch hydraulics. A falling fluid level or wetness around the bell housing area points to the slave cylinder or its line, not the disc.
  2. Do a slip test. In 4th gear at low RPM, roll into full throttle. If RPM jumps ahead of road speed, the disc or pressure plate is slipping.
  3. Listen at idle. A noise that changes when you press the pedal points to the release bearing, which is part of the slave assembly on these cars.
  4. Rule out a hydraulic problem. If the car will not release (grinds going into gear) but does not slip, bleed the system first. Air in the line mimics a failed clutch.

Why the Labor Is the Big Number

On 1997-2013 Corvettes the clutch sits at the engine, but the transmission is mounted at the rear with the differential. Corvette Central's install guide explains that the entire driveline, from the torque tube at the bell housing back to the differential, has to come out together with the rear cradle. That means pulling the shifter and console trim, disconnecting the rear brakes, suspension and exhaust, and lowering the cradle on transmission jacks. The slave line is disconnected with a Ford A/C spring-lock coupling tool, and the engine has to be supported before the last torque tube bolts come out.

How long does it take? On Grassroots Motorsports' C5 Z06 project car, professional techs who do the job regularly spent more than 10 hours removing the assemblies, rebuilding the torque tube and reinstalling everything. An experienced owner on the Grassroots Motorsports forum says the clutch alone is a 4-5 hour job on jack stands once you know how to do it. A first-timer should plan on a full weekend. Either way, the labor is the same whether you install a mild street kit or a twin-disc, which is why it pays to buy for the power you will have, not the power you have today.

C6 Corvette Clutch Kits (2005-2013)

Exedy 04952 Stage 2 cerametallic clutch kit for C6 Corvette with slave cylinder
Exedy 04952 C6 Corvette Stage 2 kit: pressure plate, 6-puck disc, hydraulic slave, pilot bearing and alignment tool.

Stage 1 Street: SPEC SC661-2

For a stock or bolt-on car that is used on the street, a Stage 1 organic kit keeps the factory feel. SPEC rates the SPEC SC661-2 Stage 1 Corvette clutch kit up to 550 ft-lbs of torque, with a 292 mm (11.5 in) carbon-Kevlar based organic disc and a double-sprung hub, per the product listing at Phastek Performance. It is built as a direct replacement that reuses the factory flywheel design. TRE Performance's listing adds that the kit works with the factory flywheel or an aftermarket flywheel modeled on the factory recessed friction surface.

SPEC's install notes call for resurfacing the factory flywheel unless you install a new one, and a break-in of at least 450 miles, mostly city stop-and-go, before any full-throttle launch or speed shift.

Stage 2 Street/Strip: Exedy 04952

For a tuned car, a cammed LS3 or a Z06 that sees track days, the Exedy 04952 Stage 2 C6 Corvette clutch kit steps up to a 6-puck cerametallic disc. Exedy's published specs (via LMPerformance and Beefcake Racing) list:

  • Torque capacity: 587 ft-lbs (Exedy notes its ratings are measured at the wheels)
  • Clamp load: 3,372
  • Disc: 11.4 in (290 mm), 26-spline, 1-3/16 in
  • Includes the hydraulic CSC slave cylinder (BRG0167)
  • Fits 2005-2007 Corvette 6.0L, 2006-2013 Corvette 7.0L and 2008-2013 Corvette 6.2L, C6 chassis, 6-speed

Exedy states its Stage 2 discs use sprung center dampers to cut shock loads into the driveline. Expect a sharper engagement than stock; a puck disc trades some smoothness for heat resistance.

C7 Corvette Clutch Kits (2014-2019)

C7 kits are listed separately from C6 kits, so shop by model year. For high-power C7s, a twin-disc is the common route. The McLeod RST twin-disc clutch with steel flywheel for the C7 Corvette is listed for 2014-2019 C7 Corvettes. McLeod's RST street twin, per Phastek Performance, is rated for 800 hp and ships with two 9.687 in organic full-face discs, a billet steel flywheel, diaphragm pressure plate, floater plate and alignment tool. It is described as having a lighter-than-stock pedal feel, which is the main reason owners choose a twin over a single-disc Stage 3.

Because the RST kit includes its own flywheel, you do not need to resurface the factory one, which saves a machine-shop trip in the middle of the job.

Flywheel: Resurface or Replace?

Corvette Central's guide says to inspect the flywheel for hot spots and, if resurfacing, remove no more than .020 in of material. A heavily heat-checked flywheel, or one already cut before, should be replaced. On the C6, SPEC's SPEC SC66A-2 aluminum flywheel for 2005-2012 Corvette is one option; browse all flexplates and flywheels for other weights. Match the flywheel to the clutch: SC661-2 is built around the factory recessed-surface design. For more on flywheel trade-offs, see our single-mass vs dual-mass flywheel guide.

Replace While You Are In There

  • Slave cylinder and release bearing: Corvette Central recommends replacing the slave assembly during any clutch job, and suggests adding an aftermarket bleeder extension to make future bleeding easier.
  • Pilot bearing if it is worn or rough.
  • Rear main seal: it is fully exposed with the flywheel off.
  • Transmission fluid: Corvette Central calls for 4.1 quarts of GM Syncromesh on the 1997-2013 cars.
  • Brake/clutch fluid: flush and bleed thoroughly before driving.

Key Torque Specs

From Corvette Central's 1997-2013 Corvette clutch install guide (always confirm against your kit's own instructions):

  • Flywheel bolts: 15 ft-lbs, then 37 ft-lbs, then 74 ft-lbs, with blue thread locker
  • Pressure plate bolts: 50 ft-lbs
  • Slave cylinder: 106 in-lbs

Cost and Effort

This is an advanced DIY job. It needs two transmission jacks or a lift, the spring-lock line tool, and room to roll the rear cradle back. Shop labor is the largest share of the bill, and it does not change much between a Stage 1 and a twin-disc. If the car is already modified or will be, buying the higher-capacity kit now is cheaper than doing the job twice. Always include the slave cylinder: a new clutch with a leaking old slave means dropping the driveline again.

Frequently Asked Questions

Will a C6 clutch kit fit a C7 Corvette?

No. The kits covered here are listed separately by generation: the Exedy 04952 fits C6 chassis cars from 2005-2013, while the McLeod RST 6406807MD is listed for 2014-2019 C7 Corvettes. Buy the kit listed for your model year and engine.

Can I reuse my factory flywheel?

With a kit designed for it, yes. SPEC says the SC661-2 reuses the factory flywheel design but strongly suggests resurfacing it. Corvette Central advises removing no more than .020 in when resurfacing. Twin-disc kits like the McLeod RST include their own flywheel.

How long is the break-in on a new Corvette clutch?

It depends on the maker. SPEC calls for at least 450 miles of mostly city driving before hard launches or speed shifts on its Stage 1 kit. Follow the instructions that come with your kit.

Find kits for your model year in our clutch kit collection, or compare stage choices on a sister LS platform in our Camaro SS Stage 1 vs Stage 2 clutch guide.
