There is no single "best" torque converter for a 68RFE, and any shop that hands you one part number without asking what the truck does is guessing. The right converter for a stock-tune Ram 2500 that tows a fifth wheel twice a year is not the right converter for a deleted, tuned 3500 pulling a gooseneck every week. What follows is how to actually pick one: what the 68RFE converter has to survive, what stall speed does and does not mean, what separates a real triple-disc from a rebuilt core, and what has to be repaired alongside it so the new converter does not kill itself.

68RFE Torque Converter O-Ring 2007-2024
The part for this fix
68RFE Torque Converter O-Ring 2007-2024
$24.99 · In stock
Shop This Part →

What You Are Working With

The 68RFE was Chrysler's first diesel-specific transmission, introduced alongside the 6.7L Cummins midway through the 2007 model year, per Diesel Hub. It is a six-speed, double-overdrive, band-less automatic with ratios of 3.23, 1.84, 1.41, 1.00, 0.82 and 0.63 to 1, with a 4.44 to 1 reverse. It uses ATF+4, weighs roughly 263 pounds, and runs dual transmission filters - a sump filter and an external cooler-return filter. Two features matter directly to converter selection: it has a dual-face torque converter lockup clutch, and it is lockup-capable in forward gears 2 through 6.

That last point is the whole reason converter choice is a big deal on this truck. The TCC on a 68RFE is not a highway-only device. It is working across most of the gear range, under diesel torque, which means the lockup clutch friction area and the quality of the lockup piston are doing real work every single day.

Stall Speed: What It Actually Means

Stall speed is the single most misunderstood spec in converter shopping. Sonnax defines it cleanly in its converter tech article by Joe Allen and Andy Dumas: stall speed is the maximum RPM at which the impeller and engine can rotate if the transmission output is constrained. Brake stall is the maximum RPM the engine can turn with the turbine held. Crucially, only two things determine brake stall - the engine's peak torque and the blade geometry (K factor) of the impeller, stator and turbine. Suspension, tires, weight and gear ratio do not influence brake stall.

The practical consequence for a Cummins owner: the stall speed printed on a converter box is only true for the engine it was rated against. Sonnax puts it directly - "the stall speed on a given converter will not be the same when coupled to a tame small block engine as it is when coupled to a high performance big block engine." If you add power to the 6.7L, the same converter will stall higher. This is why a converter that felt right at stock tune can feel wrong after a tuner and a turbo, and why the reputable diesel converter builders ask for your power level and use case before they build.

Goerend explains the mechanism the same way in its converter FAQ: engine torque and the converter itself are the two major things that determine stall speed. The company's own 68RFE offering is described as stalling roughly 500 RPM lower than stock in one configuration, specifically so it couples and tows with minimal engine RPM drop during lockup - taking advantage of the low-end torque of the 6.7L rather than fighting it.

Which direction should a 68RFE go?

For a truck that tows, lower or near-stock stall is generally the goal, not higher. A Cummins makes its torque low, so a loose (high-stall) converter mostly buys you heat and slip. Look at how the diesel converter builders configure their 68RFE units and the pattern is obvious - SunCoast's Category 1 unit is offered with 1600-1700 RPM and 2000 RPM stall options, and Diesel Performance Converters offers its 68RFE triple disc in stock, 150-under-stock, and 400-under-stock configurations. Nobody is selling a 3000 RPM stall converter for a work truck.

What Separates a Good 68RFE Converter From a Cheap One

The construction features that matter are consistent across the serious builders, and they are worth understanding before you compare anything.

  • Billet front cover. A stamped OE cover flexes under diesel torque and lockup pressure. Goerend, DPC and SunCoast all specify billet or forged steel covers. Goerend notes its cover is made from steel forgings specifically to reduce porosity.
  • Multi-disc lockup clutch. This is the biggest single difference. DPC states its triple-disc design provides three times the friction area over stock, with a new billet lockup piston, and rates the assembly at 750 HP. More friction area means less slip, less heat and a TCC that can actually hold under load.
  • Billet lockup piston. Goerend pairs its billet steel piston with a complete damper assembly, which insulates the driveline from crank pulses - a real consideration on a Cummins.
  • Furnace-brazed or TIG-welded internals. Both SunCoast and Goerend call out furnace-brazed fins and reinforced turbines. Stock fins are tabbed into place and can flatten under sustained load.
  • Hardened hubs and splines. SunCoast specifies hardened turbine splines; Goerend uses 4140 hardened turbine and flanged impeller hubs.
  • Bearings in place of thrust washers. Goerend uses a dual Torrington bearing stator design with lugged stator races; DPC uses Torrington bearings to reduce friction. This reduces heat generation inside the converter.
  • Balancing and blueprinted clearances. Goerend publishes a below 0.005 inch blueprinted runout tolerance and computerized balancing. Internal clearance directly affects both efficiency and stall.

Friction material matters too. SunCoast uses carbon-graphitic clutch material in its Category 1 unit for lockup precision. That is the kind of spec worth asking about, because a triple-disc with poor lining is still a triple-disc that glazes.

Choose By Use Case

Stock or near-stock, light towing, high mileage: A quality remanufactured or single-disc replacement built with a billet cover is usually enough. Your failure mode is age and heat, not torque capacity. Keep stall at stock.

Regular towing, mild tune, stock-ish power: This is where a triple-disc pays for itself. SunCoast describes its Category 1 unit as engineered for everyday towing and hauling duty - camper, dirt, job site - and explicitly not intended for racing. Choose the lower stall option and let the Cummins pull from the bottom.

Tuned, deleted, heavy weight, big power: You want a billet triple-disc with maximum friction area and a stall speed chosen for your specific power level, which means talking to the builder rather than picking off a shelf. Also understand that Sonnax specifically warns about programmers on these trucks: some tuners can raise line pressure, change shift points and alter torque converter lockup characteristics, and some will bring the TCC on before the 3-4 shift, "adding strain on the OD clutch as it applies without the cushion of the non-locked converter." A converter cannot save an overdrive clutch pack from a bad tune.

Fix the Lockup Circuit or the New Converter Will Fail Too

This is the part most 68RFE converter articles skip, and it is the part that decides whether your new converter lives. The 68RFE torque converter clutch is fed through the TC limit valve in the pump and the solenoid switch valve in the valve body, and both wear.

68RFE torque converter limit valve spring 2007-2024 for TCC apply circuit repair
68RFE Torque Converter Limit Valve Spring 2007-2024 - the TC limit circuit is what feeds and controls converter charge pressure. Restore it before you install a new converter.

TransGo states the case bluntly for this family: "more often than not, this transmission will come in with the TC limit valve bore in the pump that is completely wiped out," worn far enough that the pump appears to need replacing. Its SK 45RFE-A kit - which covers 45RFE, 545RFE, 65RFE, 66RFE and 68RFE from 1999 to 2018 - includes a drop-in TC limit valve system for both early and late pumps and recalibrates the TCC accumulator system, specifically to address rough lockup, TCC slide bang, TCC slip codes, converter drain-back and limp-in mode. A 68RFE shift kit is the correct companion purchase to a converter on a high-mileage unit.

On the valve body side, Sonnax's Jason Larochelle identifies the solenoid switch valve plugs as "arguably the weakest link of the Overdrive clutch system," where wear causes crossleaks that drop OD pressure, let the clutches slip, and burn them. Codes 841, 868, 871, 988, 1775 and 1776 point at that area. Vacuum test the bore before you decide.

He also flags line pressure as a root cause in both directions. Low line pressure starves the OD clutches into slipping; high line pressure can push through excessive SSV bore clearance and partially apply or fail to release the OD clutches, typically setting P0871. He notes that the line pressure sensor itself should be verified - OE line pressure adapter tool No. 8259 installs in place of the sensor so a mechanical gauge can confirm both actual pressure and sensor accuracy.

Replace While You Are In There

The transmission is out and the converter is off. Do these now:

  • 68RFE filter kit with gaskets - and remember Diesel Hub notes this unit runs dual filters, so replace both the sump filter and the external cooler-return filter.
  • Flush the cooler and lines properly. A failed converter puts debris into the cooler, and the new one will eat it.
  • Front pump seal and the torque converter O-ring - trivial parts, terrible to redo.
  • 68RFE friction clutch kit if you are already inside. Sonnax measures the OE single-sided OD frictions at only .034 inch steel core thickness, versus .080 inch for the direct clutch steels in a 4L80E, and identifies heat distortion of those thin clutches as the primary cause of OD burn-up.
  • Accumulator pistons and seals, and the solenoid block spacer kit if the conductor plate shows warp. Sonnax documents that the unsupported solenoid conductor plate warps over time, bleeding OD apply pressure away from the circuit.
  • If the unit is coming apart anyway, a 68RFE master rebuild kit with steels is the efficient path. Browse the full 68RFE parts collection and the torque converter collection to build the list.

Cost and Effort Framing

Converter cost on a 68RFE scales with three things: cover and piston material, the number of lockup discs, and whether the builder is custom-matching stall to your combination. A stock-replacement unit sits at the bottom of the range, a production triple-disc in the middle, and a made-to-order billet triple-disc with a custom stall at the top. Expect a core charge on anything reman or custom-built - it is standard practice across the industry - and factor the shipping weight of a diesel converter both ways.

Labor is the bigger number for most owners. A converter swap on a 68RFE means dropping the transmission, which is a lift or a transmission jack and a helper, not a driveway job for most people. Because the transmission is already out, the marginal labor cost of doing the valve body, the filters, the clutches and the pump work at the same time is close to zero. That is the single most important financial fact in this whole article: the converter is not the expensive part - the second removal is. Do it all once.

Related reading: our stall speed explainer, the 68RFE rebuild guide, and Allison 1000 vs 68RFE if you are weighing the platform itself.

Frequently Asked Questions

Should I get a higher stall converter for my 68RFE?

For a towing truck, almost never. The 6.7L Cummins makes its torque low in the RPM range, and the 68RFE is lockup-capable in gears 2 through 6, so a loose converter mostly adds slip and heat. The diesel converter builders reflect this - SunCoast offers its 68RFE Category 1 unit in 1600-1700 and 2000 RPM stall options, and Diesel Performance Converters offers stock, 150-under and 400-under stock configurations. Note also that Sonnax explains stall speed rises when engine torque rises, so a tuned truck will see a higher effective stall from the same converter.

Why do 68RFE torque converters fail?

Usually the lockup clutch, and usually because of the circuit that feeds it rather than the converter alone. TransGo reports that the TC limit valve bore in the pump on these units is frequently worn out completely, and Sonnax identifies solenoid switch valve plug wear as the weakest link in the overdrive circuit, causing crossleaks and pressure loss. Add a tuner that brings TCC on early and the clutch applies without the cushion of an unlocked converter. Replacing the converter without repairing those circuits is how people end up buying two converters.

Do I need to replace the transmission filters when I change the 68RFE converter?

Yes, and there are two of them. Diesel Hub lists the 68RFE as using dual transmission fluid filters - a sump filter and an external cooler-return filter - with a factory service interval of every 120,000 miles under normal service or 60,000 miles under severe duty. A failed converter also contaminates the cooler, so flush the cooler and lines before running the new unit.
