You drop the A904 into Drive, the engine loads up a little, and nothing happens. Maybe Reverse still backs up fine. Maybe manual 1 pulls but Drive does not. Maybe it is dead in every range. Those are three different repairs, and telling them apart is twenty minutes of diagnosis instead of an expensive guess.

This covers the whole small TorqueFlite family: the A904 (TF6) and its later service designations 30RH, 31RH and 32RH, plus the A998 and A999 behind Dodge, Plymouth and Jeep sixes and small-blocks. Same power flow, same failure list.

First, know what Drive actually applies

The factory TorqueFlite service manual describes the unit as two multiple-disc clutches, an overrunning clutch, two servos and bands, and two planetary gear sets. Its Clutch Engagement and Band Application Chart is the most useful page for this symptom:

  • Drive, breakaway (first gear), 2.45:1 - front clutch disengaged, rear clutch engaged, both bands released, overrunning clutch holds.
  • Second gear, 1.45:1 - rear clutch engaged, kickdown (front) band applied, overrunning clutch over-runs.
  • Drive, direct (third), 1.00:1 - front clutch and rear clutch engaged, both bands released.
  • Manual 1 (low), 2.45:1 - rear clutch engaged, low-reverse (rear) band applied.
  • Reverse, 2.20:1 - front clutch engaged, rear clutch disengaged, low-reverse band applied.

Read that chart backwards and it names your part. The rear clutch is engaged in every forward gear and is not used in Reverse, so if Reverse backs up but Drive is dead, the front clutch is fine. And since first in Drive is held by the overrunning clutch while manual 1 is held by the low-reverse band, a unit that pulls in 1 but not D has an overrunning clutch that is not holding.

The five-minute checks before anything else

The factory manual is blunt: do not remove or disassemble the unit until a careful diagnosis is made and all external corrections are performed, and always make the hydraulic pressure test before replacing parts. In order:

  1. Fluid level, hot, engine running, on level ground. Low fluid is the first item on the manual's "no drive in any position" list for a reason.
  2. Shift linkage and cable. An out-of-adjustment control cable can leave the manual valve short of the Drive detent. Verify the lever on the case reaches each position.
  3. Throttle linkage. Throttle pressure is mechanical here. A disconnected linkage rarely causes a no-move by itself, but it skews every pressure reading you are about to take.
  4. Pan and filter. A clogged filter is on the manual's no-drive list, and what is in the pan decides everything else. Bronze glitter means bushings and pump. Steel means hard parts. Black sludge means the clutch material is gone.

Pressure test: the number that splits the diagnosis

Hook a gauge to the line pressure port and compare against spec. Per the Sonnax A727/A904 pressure port reference, line pressure in Reverse should be 145-175 PSI at idle and 230-280 PSI at stall; in D2, 54-60 PSI at idle and 90-96 PSI at stall. Governor pressure should roughly equal road speed.

Low pressure everywhere means a supply problem - front pump, plugged filter, leaking valve body. Pressure in spec while Drive still will not move points past the pump to a clutch or servo that is not applying, or an overrunning clutch that is not holding.

The four causes, in the order they show up

1. Rear (forward) clutch worn or burned

The manual's "no drive in forward drive positions" list includes a worn or faulty rear clutch, and worn or broken input shaft and reaction shaft support seal rings. The seal rings are the sneaky one: the rear clutch is fed through them, so when they wear the apply oil leaks away. You can have textbook line pressure and still get no forward movement.

2. Overrunning clutch not holding

Classic signature: it pulls in manual 1, and usually still pulls in second and third once rolling, but from a stop in Drive there is nothing. Replace it as an assembly, cam and rollers inspected together.

3. Accumulator sticking, broken rings or spring

Also on the manual's no-drive-in-forward list. A cracked accumulator piston or broken spring bleeds apply pressure off the circuit it is supposed to cushion. It is cheap, it sits right at the valve body, and it gets skipped constantly.

4. Front pump, valve body and the line pressure plug

If nothing moves in any range, the manual's list is short: low fluid, low pressures, clogged filter, valve body malfunction or leakage, faulty front oil pump, or clutches and servos sticking. Sonnax adds one wear item: a worn line pressure plug and sleeve causes slippage in reverse, poor cooler charge at idle and poor forward and reverse engagements, because the pressure regulator valve can no longer control line pressure. Their A904 repair is kit 12229-01K.

A904 30RH deluxe transmission rebuild kit with frictions, steels, gaskets and seals
Shop rebuild kits for the A904 and 30RH →

The fix, by finding

If the pan came out clean and the problem is hydraulic - accumulator, seal rings, line pressure plug, a stuck valve - you can fix it with the unit in the vehicle. Start with the A904 accumulator piston kit and a fresh A904 Dacron transmission filter, and inspect the pressure regulator and line pressure plug bores on the bench.

If the pan had friction material or metal in it, the rear clutch is cooked and the debris is already in the cooler and converter. That is a full overhaul with an A904 deluxe transmission rebuild kit, not a patch - and flush or replace the cooler and the converter, or you feed the same debris back into the new clutches.

One upgrade while the valve body is out: Sonnax notes the cooler and converter charge circuit does not open until the pressure regulator valve moves far enough to flow oil, starving lube on startup. Their lube-regulated PR valve 22771A-02K feeds that circuit as soon as the engine starts. Their caution - only use it if the original PR valve's inboard spools step progressively smaller, like a Christmas tree.

Replace while you are in there

  • Filter and pan gasket - always, see transmission filters.
  • Front and rear bands plus struts and anchors if the unit is apart.
  • Overrunning clutch assembly - see sprags and roller clutches.
  • Input shaft and reaction shaft support seal rings, and the thrust washer set.
  • Front pump bushing and seal any time the converter is out.
  • Governor support - Sonnax notes lube failures here show up as galled governor supports, seized output shafts and rounded gears.

Band adjustment specs

Do not guess the turn count. Per ATRA Technical Bulletin #1151 (Band Adjustment Chart, January 2008): 30RH and 32RH in Cherokee and '94 applications back off 2-1/4 turns front, 4 turns rear; all other 30RH/32RH are 2-1/2 turns front, 4 turns rear. On the earlier TF6 the front band is 2 turns on both six- and eight-cylinder units, rear band 7-1/2 turns solid or 4 turns wrap.

The factory procedure: loosen the lock nut and back it off about five turns, confirm the screw turns freely, then tighten it to 47-50 in-lb using tool C-3380 with adapter C-3705 - or 72 in-lb, the manual's true torque, without the adapter - then back it off the specified turns and hold it while you torque the lock nut. The manual calls for 25 ft-lb on the A904 kickdown lock nut, 20 ft-lb on the low-reverse lock nut, and 150 in-lb on the pan bolts.

Cost and effort

A pan, filter and band adjustment is an evening in the driveway; the only special tool is the band adjusting wrench. Pulling the valve body is a step up but still in-vehicle. A full overhaul means pulling the unit - a weekend for a first-timer, or a day's labor at a shop. The cost spread between those three jobs is exactly why the pressure test comes before the parts order.

FAQ

It moves in manual 1 but not in Drive. What is that?
Almost always the overrunning clutch. Manual 1 is held by the low-reverse band; first in Drive is held by the overrunning clutch. Same ratio, different holding element - and only one of them is failing.

Reverse works but Drive is dead. Is the transmission junk?
Not necessarily. Reverse uses the front clutch and low-reverse band; forward uses the rear clutch. If the pan is clean, there is a real chance it is a seal ring or accumulator rather than a burned pack.

Do I have to replace the torque converter?
If the failure produced friction material or metal, yes. A converter cannot be cleaned in place, and it will keep feeding debris into the fresh clutches until it takes them out too.

Working on the big-block instead? See A727 TorqueFlite no reverse, band adjustment specs and the real fix.
