Your Toyota A340E or A340F has a fresh filter, new fluid, and maybe even new solenoids, yet it still engages late into Drive or Reverse, shifts soft, cooks its fluid, or sets torque converter clutch codes. When the easy parts check out, the problem is often something you cannot see without taking the valve body apart: bore wear. That means the aluminum bores the valves slide in have worn oversize, and pressure that should stay in a circuit leaks straight to exhaust. This guide covers which A340 bores wear, the symptoms each one causes, how shops confirm it, and what the real repair looks like.

What Bore Wear Actually Is

Every spool valve in an A340 valve body runs in a machined bore with very little clearance. That tight fit is the only thing sealing one hydraulic circuit from the next. Sonnax explains that the steel OE valves ride against cast aluminum, and valves that are always moving slowly wear the bore. As clearance grows, fluid slips past the spools. Line pressure, converter feed, and cooler flow all drop, or in some cases pressure climbs because a balance circuit is leaking.

Bore wear does not go away with fluid changes, additives, or new solenoids. A solenoid can command pressure perfectly and the valve it feeds will still leak if its bore is worn.

Symptoms of A340 Valve Body Bore Wear

Sonnax ties specific complaints to specific worn bores on the A340 family:

  • Main pressure regulator valve bore: low line pressure, high line pressure, poor shift quality, low lube oil flow, and burnt clutches. According to Sonnax, wear at the inboard balance spools lets line pressure fluid escape, causing excessively high pressure, harsh shifts and reduced cooler/converter flow. Wear at the outboard spools robs converter feed and lowers line pressure, causing soft shifts and burnt clutches and brakes.
  • Lockup relay valve bore: TCC apply and release concerns, TCC codes, poor lubrication, overheated fluid, and bushing failure. Sonnax notes this valve sends converter feed to the release side of the converter clutch and apply fluid into the cooler circuit, so wear here starves both.
  • Boost valve and sleeve: delayed engagement, low line rise, low or high line pressure in Reverse, erratic line pressure, soft upshifts, and repeated clutch failure. On Type 1 units, Sonnax says the steel OE valve wears its cast aluminum sleeve until the valve no longer works properly.
  • Secondary pressure regulator valve bore: TCC apply and release concerns, burnt TCC apply parts, and an overheated transmission, per the Sonnax A340 valve body layout.

If your truck shows several of these together, especially heat, soft shifts, and TCC codes, suspect bore wear before blaming the transmission's hard parts. For a broader look at how these symptoms show up, see our guide to A340 valve body common failure points.

Step 1: Identify Which A340 Valve Body You Have

The fix depends on the casting, because parts do not cross between generations. Per the Sonnax A340E/F identification guide and valve body layout:

  • Type 1 (casting codes 8930 upper / 8931 lower): earlier units with three or fewer solenoids and a TV cable. Sonnax lists the 97855-series boost valve, pressure regulator, and lockup relay parts for this casting.
  • Type 3 (casting ID 8935): 2000-and-later V8 applications, EPC throttle control only.
  • Type 4 (casting ID 8938): 2000-and-later V6 or V8 applications, EPC or cable throttle control.

Gears Magazine describes the same timeline: early A340 valve bodies (1985-2000) used on/off shift and lockup solenoids, the 2000 update added the SLT (EPC) solenoid and dropped the TV cable, and 2005-later units moved to a modulated SLU lockup solenoid. Read the casting number on your upper and lower valve body before you order anything.

Step 2: Confirm the Wear With a Vacuum Test

You cannot judge bore wear by eye. The standard shop method is a vacuum test. Sonnax describes how it works: a vacuum pump pulls through the gap between the valve spool and bore, and a gauge reads the result. More wear means more leakage and a lower reading. Sonnax puts the numbers this way:

  • A perfect seal would read 29.9 inches of mercury, which no real circuit reaches.
  • An extremely good circuit might read about 22 to 23 inches.
  • A severely worn bore can read as low as 8 inches.

Sonnax notes that each rebuilder has to establish their own pass/fail standards from experience. If you do not own a vacuum stand, a transmission shop can test the valve body for you, or you can skip testing and replace the valve body. Our walkthrough on how to test an A340 valve body before you replace it covers the in-vehicle checks to do first.

Step 3: The Real Fix, Drop-In or Ream and Oversize

Depending on how badly the bore is worn, there are two repair paths.

Drop-in repairs (light to moderate wear)

Where the OE part wears its own sleeve, a new sleeve and valve restores the seal with no machining. On late Type 3 and 4 valve bodies, Sonnax lists a dual-ratio boost valve kit (97741-01K) for delayed Reverse, delayed Forward, soft upshifts and low pressure, a lockup relay control valve kit (77741-02K) for TCC concerns, TCC codes and RPM fluctuation, and an O-ringed end plug kit (97741-19K) for soft shifts, low line rise, and slips and flares.

A340E Sonnax dual-ratio boost valve kit 97741-01K with boost sleeve, EPC boost valves, reverse boost valve and shims
The A340E Sonnax Dual-Ratio Boost Valve Kit 97741-01K replaces the worn boost sleeve and valves on 2000-later Type 3 and 4 valve bodies.

Shop the drop-in parts: the A340E dual-ratio boost valve kit, the A340E lockup relay control valve kit, and the A340E O-ringed end plug kit.

Ream and oversize (severe wear)

When the bore itself is worn too far for a drop-in part, Sonnax's listed correction is to recondition (ream) the bore and install an oversized valve. For the A340E/F main pressure regulator, Sonnax lists oversized kit 97741-10K for Type 3 and 4 valve bodies with a .353 inch EPC (small) spool, and 97741-06K for units with a .426 inch spool. Sonnax warns you must measure the EPC spool on the OE boost valve to confirm fit. The lockup relay bore uses oversized kit 97741-20K on 2000-later Type 3 and 4 bodies. These kits need a matching reamer and fixture (Sonnax lists F-97741-TL6 and F-97741-TL20, and notes some tooling is no longer in production), so reaming is a shop job, not a driveway job.

When a complete valve body makes more sense

If several bores test worn, or you have no access to reaming tools, a complete replacement valve body is usually the faster route. Browse our transmission valve bodies and our shift kits and valve body repair parts.

Replace While You Are In There

  • Solenoids: Sonnax lists solenoid failure among the results of lockup relay wear, so test resistance and function while the valve body is out. See the A340E shift solenoid kit and the A340E TCC lock-up solenoid kit (2000-2015).
  • End plugs: leaking end plugs cause the same soft-shift complaints as worn bores.
  • Filter, pan gasket and fluid: always, since worn bores often come with burnt fluid and debris.
  • Cooler flush: low cooler flow from lockup relay or regulator wear can leave debris in the lines.

Cost and Effort

Removing and reinstalling the valve body is moderate work for a home mechanic with a torque wrench and a clean bench. Drop-in valve and sleeve kits are within reach of a careful DIYer working from the Sonnax instructions. Reaming for oversized valves needs dedicated fixtures and a vacuum stand to confirm the result, so most owners either send the valve body to a shop or install a complete replacement. For a fuller breakdown, read A340 valve body replacement cost and whether it is worth it.

Frequently Asked Questions

Can new solenoids fix A340 bore wear?

No. Solenoids control the signal pressure, but if the valve bore downstream is worn, fluid still leaks past the spool. New solenoids will not restore line pressure, converter feed or cooler flow lost to bore wear.

Which A340 valve body bores wear the most?

Sonnax targets the main pressure regulator, lockup relay, secondary pressure regulator and boost valve areas on the A340 family. These valves move constantly, and their wear causes line pressure problems, TCC codes and overheated fluid.

Do Type 1 and Type 3/4 A340 valve bodies use the same repair parts?

No. Type 1 (8930/8931 castings) uses the 97855-series Sonnax parts, while 2000-later Type 3 (8935) and Type 4 (8938) valve bodies use the 97741-series and 77741-02K parts. Check your casting numbers first.
