You get a car in with a complaint that sounds like an engine problem. The customer says it feels like a misfire — a low-speed rumble, worse under light throttle, mostly under 60 mph. You pull codes and there is nothing. No misfire counters, no transmission DTCs, no TCC codes. Fuel trims are clean, plugs and coils are fine, and a tank of good fuel changed nothing.

If that car is a 2019–2024 Ford Edge or a 2019–2023 Lincoln Nautilus with the 8F35 eight-speed, stop chasing the engine. Ford has a bulletin on this exact complaint, and the cause is not in the engine and not in the torque converter clutch the way most shudder complaints are. It is the output planetary assembly.

What the bulletin actually says

Ford TSB 26-2171 (17 April 2026), filed with NHTSA, describes vehicles that exhibit all of the following: a shudder condition most noticeable at speeds below 60 mph (100 km/h), no relevant diagnostic trouble codes present, and a traceable shudder event when reading with IDS or FDRS. The bulletin states plainly that the condition may be perceived or felt as an engine misfire, and that it may be due to a concern with the output planetary assembly.

That bulletin updated an earlier one (25-2154) to revise the parts list and the service procedure for replacing the output planetary carrier assembly, and to add 2023–2024 model year vehicles. It has since been superseded by TSB 26-2341, which adds a parts-list note clarifying that two specific part numbers apply to front-wheel-drive vehicles only. Same condition, same cause — only the hardware application note changed. Verify the FWD versus AWD callout against the current bulletin before you order anything.

The verification step matters as much as the diagnosis. Per the bulletin, the shudder must be traceable on a scan tool — you are watching torque converter slip data (TC_SLIPACT versus TC_SLIPDSD) and looking for a real, repeatable event, not a subjective road-test impression. If you cannot capture it, you do not have this concern and you should not be tearing the unit down.

Why a planetary makes a "misfire" feeling

This is where a lot of good techs get thrown. A shudder that rises and falls with road speed under light load reads like TCC shudder or an engine misfire because all three produce the same low-frequency pulsing in the same speed band. But a worn planetary does not throw a code — it does not have a solenoid, a pressure switch, or a ratio monitor watching it directly. It just introduces mechanical roughness into the output path, and the driver feels it in the seat.

Ford has already documented the underlying wear mechanism on the same transmission family in a different application. TSB 22-2281 covers 2019–2021 Transit Connect vehicles built on or before 20-Dec-2021 with the 8F35, which may exhibit transmission slipping, harsh engagements and various clutch DTCs (and on some vehicles, torque converter clutch DTCs). Ford attributes that condition to worn needle bearings in the output planet carrier assembly, and the correction is to overhaul the transmission and replace the planetary gearset.

Read those two bulletins together and the picture is clear: the needle bearings in the 8F35 output planet carrier wear. Depending on how far it has gone and what the application is, you get either the coded version (slipping, harsh engagement, clutch codes) or the silent version (a low-speed shudder with nothing stored). Same hardware, different stage.

Diagnosis order before you pull the unit

This is a transmission-out, teardown-level repair. Earn it before you sell it:

  1. Rule out the engine honestly. Misfire monitors, fuel trims, a relative compression test if you have it. A real misfire almost always leaves a footprint somewhere.
  2. Check the fluid the right way. The 8F35 uses Motorcraft MERCON ULV meeting Ford specification WSS-M2C949-A — an extremely thin fluid. It is not interchangeable with MERCON LV or MERCON V, and the wrong fluid alone will make an 8-speed shudder. There is no conventional dipstick, and the level is checked with the fluid brought to roughly 185–200°F (85–93°C) on a scan tool. Cold-checking and guessing is how these units end up over- or underfilled.
  3. Confirm the software level. Ford's procedure ends with reprogramming the PCM to the latest calibration. Do that step first as a standalone check — if a calibration alone resolves the complaint, you just saved a teardown.
  4. Capture the event. Get the traceable shudder on IDS/FDRS with converter slip data. That recording is your evidence, your authorization, and your before-and-after.
  5. Only then commit to the teardown.

The fix, and what you replace while you are in there

The bulletin's service procedure is a transmission removal and disassembly. The output planetary carrier assembly comes out and is discarded, and a new one goes in. Both internal transmission fluid filters and the torque converter hub seal are replaced, the main control valve body is overhauled and cleaned, and the torque converter is replaced. The PCM is then reprogrammed.

Ford 8F35 planetary set - output planet carrier assembly for Edge and Nautilus shudder repair
Shop the 8F35 planetary set for the output carrier repair →

The part that fixes the complaint is the 8F35 planetary set. Everything else on the list is there because the unit is already on the bench and because debris from a failing needle bearing does not stay in the carrier — it circulates. That is why Ford calls for both internal filters and a cleaned valve body rather than just the carrier.

Replace-while-you-are-in-there list, in order of "you will regret skipping this":

  • Both internal transmission filters. Non-negotiable. Bearing debris went somewhere.
  • Torque converter hub seal, and the converter itself per the bulletin.
  • Full gasket and seal set. If you are this deep, an 8F35 rebuild kit is cheaper than going back in for one seal.
  • Frictions and steels if the unit has miles on it or if you found clutch material in the pan. You will never have a better shot at them.
  • The correct FWD or AWD hardware — axle seals and retaining straps differ, which is exactly what the superseding bulletin clarified.

Browse transmission filters and match the filter to your build year before the unit comes apart, not after.

Cost and effort framing

Set expectations honestly. This is a remove-and-overhaul job on a transverse eight-speed in a unibody crossover. Realistically you are looking at subframe-level access, cradle work on some applications, and a full teardown to reach the output carrier — a multi-day job in most shops, not an afternoon. Book it like an overhaul, because functionally that is what it is.

Difficulty is high. This is not a driveway repair. You need a lift, a transmission jack, the correct ULV fluid, and a scan tool capable of the fluid-level temperature procedure and PCM reprogramming. If you cannot reprogram, you cannot finish the bulletin procedure correctly.

One more thing to tell the customer before they leave: the 8F35 uses an adaptive shift strategy. After the repair and the PCM reset, the vehicle may shift firmer than normal for several days while the module relearns. That is expected behavior, not a comeback — but if you do not say it up front, you will get the phone call.

Know what you are working on

The 8F24, 8F35, 8F40 and 8F57 are Ford's front-wheel-drive eight-speeds, all in production since 2019, mated to different engine sizes and torque capacities, per Sonnax's identification guide by Jim Dial. The valve bodies have different variations including solenoid configurations, and Sonnax notes the best quick-identification points are the bottom right side of the valve body casting and the valve-body-to-case bolt locations. Confirm which unit you actually have before ordering hard parts — these four are close enough to burn you.

For reference, the 8F35 runs a 4.689:1 first gear down to a 0.617:1 eighth, with a 2.960:1 reverse, and takes roughly 11.6 quarts dry fill of MERCON ULV.

FAQ

Is this the same thing as normal torque converter shudder?
No, and that is the trap. Classic TCC shudder is a lockup-clutch or fluid problem and usually responds to a fluid exchange or a converter. This bulletin's condition has no DTCs, is traceable on converter slip data, and Ford attributes it to the output planetary assembly. If a fluid service and a converter did not fix a low-speed 8F35 shudder, the carrier is where to look next.

Will a fluid change fix it?
It will not fix worn needle bearings in the output planet carrier. It is still worth doing first, because the wrong fluid or a bad level will produce a similar complaint on this unit and that is a far cheaper answer. Use MERCON ULV to WSS-M2C949-A only, and check level at temperature.

My Edge throws no codes at all. Am I sure it is the transmission?
"No relevant DTCs present" is part of the bulletin's own condition statement, so the absence of codes does not rule it out — it is a criterion. What rules it in is the traceable shudder event on IDS or FDRS. Get the recording before you commit.

What if I am getting P0766 or P0767 instead of shudder?
That is a different 8F35 failure path entirely. We covered that one separately in Ford 8F35 no reverse: P0766 vs P0767.
