The GM 700R4 has been in service since 1982, and after four decades of street, tow and strip duty the failure pattern on this transmission is extremely well documented. It is not random. The same handful of parts give up, in the same order, for the same reasons - and most of those reasons trace back to hydraulic pressure, heat, or one cable that almost nobody adjusts correctly.
