If you landed here trying to decide between a GM 6L90 and a Chrysler 62TE, the honest first answer is that these two six-speeds almost never compete for the same job. They share a gear count and nothing else. The 6L90 is a longitudinal, rear-wheel-drive Hydra-Matic built for three-quarter-ton and one-ton trucks. The 62TE is a transverse front-wheel-drive transaxle built for minivans, midsize sedans and the ProMaster van. You cannot swap one for the other, and the parts do not interchange in any direction.

Parts for your 6L90

6L90 Advanced Rebuild Kit - Frictions & Steels, Gaskets & Seals, Filter, Shift Kit, Servo (5-Piece) — $396.99

See all 6L90 rebuild kits

Get the parts for this repair
Shop 6L90 Parts →

Where the comparison genuinely matters is when you are shopping a used vehicle, spec'ing a swap donor, or trying to understand why the repair estimate on one is so different from the other. Below is the real spec split, the failure points each unit is actually known for, and how the rebuild economics compare.

The core architectural difference

The 6L90 is a rear-drive unit in a die-cast aluminum case, running DEXRON VI, with a 29-spline output shaft on most truck applications, per DieselHub's 6L90 specification sheet. Novak Conversions notes that some two-wheel-drive vans and HD truck versions used a 36-spline output instead, and that the 6L90 runs about 1-3/8 inches longer than the 6L80 with roughly 25 percent of its internal parts differing.

The 62TE is the opposite layout entirely. Action Transmission describes it as "an evolution of Chrysler's 41TE four-speed automatic transmission," which is the key thing to understand: it is a transverse four-speed architecture extended to six forward speeds, with the differential and final drive living inside the same aluminum case. The whole assembly sits sideways in the engine bay driving the front wheels.

Ratios and torque capacity

DieselHub lists the 6L90 gear ratios as 4.027 (1st), 2.364 (2nd), 1.532 (3rd), 1.152 (4th), 0.852 (5th), 0.667 (6th) and 3.064 reverse, with a maximum input torque figure of 531 lb-ft. Novak gives the 6L90 an output torque rating of 885 ft-lbs against the 6L80's 664 ft-lbs, and rates the 6L90 for 15,000 lbs GVW and 21,000 lbs GCVW. Ratings vary with calibration and application, so treat these as family-level figures rather than a promise for one specific truck.

GearboxList lists the 62TE for a 2008 Grand Voyager 3.8L at 4.127 (1st), 2.842 (2nd), 2.283 (3rd), 1.452 (4th), 1.000 (5th) and 0.690 (6th), reverse 3.214, with a 3.246 final drive. Torque capacity is the headline gap: Action Transmission puts the 62TE at up to 280 lb-ft, and GearboxList lists up to 400 Nm. Either way, the 6L90 is in a different weight class by a wide margin. That is not a knock on the 62TE, it is simply what a front-drive minivan transaxle is designed to carry.

Fluid, capacity and service

These two do not share a drop of fluid spec. DieselHub specifies DEXRON VI for the 6L90 with roughly 13 quarts total capacity and an approximate 245 lb weight including torque converter and ATF. GearboxList specifies Mopar ATF+4 (MS-9602) for the 62TE at 8.5 liters, with a fluid and filter service interval of every 60,000 km.

Putting DEXRON VI in a 62TE is a real-world mistake that shows up in shops. ATF+4 is a specific Chrysler friction-modified spec, and the 62TE clutch packs and torque converter are calibrated around it. Use what the case tag calls for.

Applications you will actually find them in

DieselHub lists the 6L90 in 2007-current Chevrolet Silverado 2500HD/3500HD and GMC Sierra 2500HD/3500HD, plus 2010-current Chevrolet Express 2500/3500 and GMC Savana 2500/3500.

GearboxList lists the 62TE from roughly 2006 through 2020 across the Chrysler 200, Sebring, Grand Voyager, Town & Country and Pacifica; Dodge Avenger, Journey and Grand Caravan; and the Volkswagen Routan from 2008-2013. Action Transmission adds the Ram ProMaster and Jeep Compass to that list.

What actually fails: 6L90

Sonnax technical staff catalog the 6L90's no-movement and pressure complaints in detail, and almost all of them trace to the valve body, the pump or the TEHCM rather than to hard parts. From Sonnax's 6L series no-movement analysis:

  • Line pressure stuck at roughly 60-68 psi with no rise on RPM is a classic TEHCM line pressure solenoid stuck in exhaust mode. Sonnax notes the reading is no different with the unit unplugged.
  • Pump TCC control valve stuck against the spring blocks converter charge oil and is usually a no-movement condition. Depending on where it hangs, it can instead show up as shudder on TCC apply or when coasting to a stop. Sonnax notes this valve can be air-checked in-vehicle with the valve body removed.
  • A missing pressure regulator boost valve roll pin drops line pressure to 30 psi or less at idle. There may be some movement, but it will not be normal.
  • Wrong separator plate for the valve body type. A Type 2 plate on a Type 1 valve body gives no Forward; a Type 1 plate (#24245720, seven checkballs) on a Type 2 valve body gives no 3rd and no Reverse. Line pressure reads normal in both cases, which is what makes it so easy to misdiagnose. Sonnax also notes early Type 1 valve bodies cannot be updated to the later eight-checkball plate.
  • Clutch select valves or springs installed backwards cause loss of Forward, Reverse or both. Sonnax's rule: valves go in first, springs outboard.
  • A TEHCM whose part number and program file do not match the VIN can produce a no-movement or no-upshift condition on its own.

The practical takeaway on a 6L90 is that a huge share of the complaints are solved inside the control valve body, not by pulling the unit apart.

6L90 control valve body with TCM, 2006-2017, OEM 24275873
6L90 Control Valve Body with TCM, 2006-2017 (OEM 24275873) - the part most 6L90 pressure and no-movement complaints actually come back to.

What actually fails: 62TE

The 62TE has one failure point that has become genuinely well documented. In Sonnax's July 2025 write-up on 62TE and 68RFE low/reverse switch valve issues, product line manager Chris Leach explains that in the 62TE the low/reverse switch valve acts as a one-way valve for the low/reverse clutch in Reverse and Drive, and the low clutch switch valve does the same for the low clutch.

Per Sonnax, wear in those bores lets fluid leak past the one-way valve and exhaust through the manual valve. The result is low apply pressure, which "will cause burnt clutches and delayed - or even no - Reverse or 1st and 2nd Gears." Sonnax attributes the wear to the valve being heavily side-loaded, likely because its diameter is too close to its total length.

The diagnostic detail is the useful part. Sonnax states that vacuum testing these bores is difficult because of a very long port that must be covered front and back, and that you must manually shuttle the valve into the port being tested. Their threshold: 18 inches of mercury is satisfactory, and anything below that is worn and should be replaced. They also note that if port #1 shows excessive leakage, leakage at port #2 is almost assured, so plan on replacing both OE valves. Sonnax's repairs use inboard and outboard sleeves with a checkball, offered as drop-in kit 92835-43K and oversized kit 92835-47K for extreme bore wear.

Beyond that valve, Action Transmission cites solenoid pack wear as a recurring 62TE failure, since the pack regulates hydraulic flow, along with torque converter faults and overheating. GearboxList adds the low-pressure drum breaking, EPC sensor failures, and bushing and speed sensor wear at high mileage.

62TE shift solenoid kit for 2007-up Chrysler and Dodge front-wheel-drive applications
62TE Shift Solenoid Kit, 2007-Up - the usual answer when a 62TE starts shifting erratically or drops to limp.

Replace-while-you-are-in-there

On a 6L90, if the pan is down and the valve body is out, do the pressure regulator and boost valve area, the TCC regulator valve, the filter and pan gasket, and verify the separator plate matches the valve body type before it goes back together. Browse the full 6L90 valve body and valve body repair kit selection to line up the right casting and the correct-generation plate.

On a 62TE, if you are already in the valve body for the low/reverse switch valve, address the low clutch switch valve at the same time on Sonnax's own advice, and replace the solenoid pack, filter and pan gasket while access is open. The 62TE solenoid and solenoid pack collection covers the shift solenoid side.

Cost and effort framing

The labor picture is where the two really diverge. A 6L90 valve body or TEHCM job is done from underneath the truck with the pan down, and on many HD applications the transmission is accessible without pulling the cab or the engine. Book time on a valve body replacement typically runs a few hours, and a first-time DIYer with a lift or good stands can do it in a weekend.

A 62TE is a transaxle. Anything deeper than the pan, filter and solenoid pack usually means the unit comes out of the vehicle, which on a minivan or ProMaster means pulling the subframe or dropping the powertrain cradle. That structural reality is why a 62TE internal repair carries far more labor than an equivalent-sounding 6L90 job, even though the 62TE is the smaller, lighter unit.

Which one to choose

If you are towing, hauling, or building anything rear-drive, the 6L90 is the only one of the two in the conversation. It is rated for 15,000 lbs GVW per Novak and carries a substantially higher torque capacity. If you are buying or keeping a front-drive Chrysler minivan, Journey, 200 or ProMaster, the 62TE is what came in the vehicle and there is no practical alternative to it in that chassis. Choose based on the platform, not on the transmission.

For a closer, more directly comparable matchup, see our breakdown of the 6L80 vs 62TE differences, since the 6L80 shows up in half-ton trucks and SUVs that a shopper might realistically cross-shop against a front-drive people mover.

FAQ

Can a 6L90 be swapped in place of a 62TE?
No. The 6L90 is a longitudinal rear-drive Hydra-Matic; the 62TE is a transverse front-drive transaxle with the differential built into the case. There is no bellhousing, mounting, driveline or control-system path between them.

Do any 6L90 and 62TE parts interchange?
None. Different manufacturers, different architectures, different fluid specs. The 6L90 runs DEXRON VI per DieselHub; the 62TE runs Mopar ATF+4 per GearboxList.

My 62TE has no Reverse and delayed 1st and 2nd. Is the transmission finished?
Not necessarily. Sonnax identifies low/reverse switch valve and low clutch switch valve bore wear as a direct cause of exactly that symptom set through low apply pressure. Vacuum test the bores before condemning the unit, using Sonnax's 18 in-Hg pass threshold. If clutches are already burnt from running on low pressure, that is a separate repair, but the valve is the root cause to correct either way.
