Your 68RFE throws a shift code, drops into failsafe, starts in second with the check engine light on, or burns an overdrive clutch shortly after a rebuild. The valve body gets replaced or cleaned, the truck is fine for a while, and then the same complaint comes back. In many of these trucks the root cause is not a stuck valve or dirty fluid. It is bore wear: the aluminum bore a steel or aluminum valve rides in has worn oversize, and no amount of cleaning or new springs will seal it again.

68RFE Valve Body 2007-2024 OEM 5170877AA
The part for this fix
68RFE Valve Body 2007-2024 OEM 5170877AA
$490.99 · In stock
Shop This Part →

This guide explains how 68RFE valve body bores wear, how to confirm it with a vacuum test instead of guessing, and what actually fixes it. Every spec and part number below comes from Sonnax's published tech articles and product pages. For a full list of wear spots on this unit, see our 68RFE valve body common failure points article.

Why Valve Body Bores Wear in the First Place

A hydraulic valve has to stroke to control fluid, so it cannot be a press fit. In Sonnax's valve body inspection and reaming article, Bob Warnke gives the total diametrical valve-spool-to-bore clearance as .0005 in. minimum to .0016 in. maximum. That is thinner than a human hair, which he puts at about .0034 in. The clearance holds a thin oil film that supports the valve as it moves.

Three things open that clearance up over time:

  • Contamination. Warnke explains that any particle larger than the clearance can become embedded as it travels with the valve and score the softer of the two surfaces. In a valve body that is the aluminum casting.
  • Side loading. Fluid pressure pushes the valve against the far side of the bore. Warnke notes that a worn bore shows a polished crescent on that side when you look in from the direction the fluid enters.
  • Constant cycling. Sonnax's vacuum testing article explains that the busiest valves wear first. Regulating valves and valves controlled by modulated solenoids oscillate in a narrow section of the bore, which creates wear exactly where the seal matters most.

Once clearance grows, fluid leaks past the valve, pressures go out of spec, and the transmission computer loses precise control of the clutches. That is when codes and burnt clutches start.

The Bores That Wear on a 68RFE

Solenoid Switch Valve Bore

This is the headline wear point on the RFE family. On the product page for its 92835-31K kit, Sonnax explains that the solenoid switch valve and plugs cause bore wear as they oscillate and stroke. The wear allows pressure loss and cross-leakage and often lets the plugs cock and hang up in the bore. Sonnax's RFE vacuum test guide lists the resulting symptoms:

  • Codes 841, 868, 871, 988, 1775 and 1776
  • Bind-up and failsafe mode
  • Burned overdrive clutch or burned 4th clutch
  • Second-gear starts with the MIL on
  • Wrong gear starts

Low/Reverse Switch Valve Bore

In a July 2025 Sonnax article, product line manager Chris Leach explains that this valve works as a one-way valve for the low/reverse clutch in Reverse and Drive. It wears its bore because it is heavily side-loaded, likely because its diameter is too close to its total length. Fluid then leaks past and exhausts through the manual valve. The result is low apply pressure, a burnt low/reverse clutch, and delayed or even no Reverse, 1st or 2nd gear.

Accumulator Piston Bores

The vacuum test guide ties accumulator piston wear to slide shifts, high CVIs, 1-2 shudder and coastdown clunk. Sonnax's universal remanufactured RFE valve body uses heavy duty accumulator pistons with dual-guide seals specifically to prevent piston-to-bore scuffing.

How to Confirm Bore Wear: Vacuum Testing

Swapping parts on a hunch is how the same complaint comes back. Sonnax's "Vacuum Testing for Leakage" article explains the method: you seal a circuit containing one or two valve spools and try to pull air between the spool and bore. Tight clearance holds vacuum. Worn clearance leaks it. Sonnax states that vacuum loss is directly proportional to the amount of wear.

What the numbers mean, according to Sonnax:

  • A perfect vacuum measures 29.9 in-Hg, which varies with elevation. No real valve circuit reaches it.
  • In Sonnax's example of a pressure regulator bore, an extremely good circuit might read 22 or 23 in-Hg, and a severely worn bore could read as low as 8 in-Hg.
  • For the 68RFE low/reverse switch valve bore specifically, Leach states that 18 in-Hg is satisfactory and anything below is worn and should be replaced.

Testing tips from the Sonnax articles:

  1. Test the valves in rest position unless the guide says otherwise. The RFE guide tells you to center the solenoid switch valve spool in the opening and test next to the bore plug.
  2. Shuttle the low/reverse switch valve by hand. Leach notes you have to move it into each worm track area to get a reading on the 68RFE.
  3. Do not seal the neighboring port that supplies the air for the test. Sonnax warns this gives a false high reading.
  4. Look before you test. A polished crescent, a flower-petal pattern or a visible step in the bore are visual signs of wear, per Warnke.

If you have not pulled the valve body yet, start with our guide on how to test a 68RFE valve body before you replace it, which covers the electrical checks that should come first.

The Real Fix: Recondition the Bore, Do Not Just Replace the Valve

A new OE-size valve in a worn bore still leaks, because the bore is what wore. The fix is to ream the bore to a new, true size and install an oversized valve made to fit it, or replace the whole valve body with one that has already been corrected.

Step 1: Measure the OE Switch Valve

Sonnax warns that Chrysler solenoid switch valves measure either .420 in. or .453 in. on the large spool, and the repair depends on which one you have. Measure before ordering.

Step 2: Match the Kit to the Wear

Sonnax states that standard-size kits address low to moderate bore wear, while oversize kits address excessive bore wear. For the .453 in. valve, Sonnax lists:

  • 92835-39K solenoid switch valve plug kit, no tool required
  • 92835-22K oversized plug kit, reamer 92835-RM22
  • 92835-31K oversized valve and plug kit, tool kit F-92835-TL31
Sonnax 92835-31K oversized solenoid switch valve and plug kit for the 68RFE valve body
68RFE Sonnax Oversized Solenoid Switch Valve and Plug Kit 92835-31K

For a worn .453 in. bore, the Sonnax oversized solenoid switch valve and plug kit 92835-31K is the complete repair. Sonnax says it uses patented plugs redesigned to prevent cocking, an O-ringed end plug that seals the bore, annular grooves that center the valve and plugs to prevent future side-load wear, and a hardcoat anodized aluminum valve and plugs. If testing shows only light wear and the plugs are the issue, the Sonnax solenoid switch valve plug kit 92835-39K drops in without reaming.

Sonnax also notes that for .420 in. valves it now recommends the 92835-32K kit with tool kit F-92835-TL32 for an improved reaming experience and results. For a worn low/reverse switch valve bore, Leach lists the drop-in 92835-41K checkball sleeve kit and the oversized 92835-45K for extreme wear.

Step 3: Use the Right Tooling

Sonnax's F-Tool kits, including F-92835-TL31, contain a reamer, reamer jig and guide pin, and all require the VB-FIX self-aligning valve body reaming fixture. This is precision machining. Hand-reaming a bore without a fixture risks cutting it out of line, which is worse than the wear you started with.

When a Remanufactured Valve Body Is the Better Fix

If vacuum testing finds several worn bores, or you do not have the reamers and fixture, a corrected valve body is the practical answer. Sonnax describes what its universal remanufactured RFE body addresses: a channel casting resurfaced to SAE recommended flatness to eliminate warpage and cross-leaks, a new separator plate and gaskets, dual-guide-seal accumulator pistons, patented Sonnax valves, and a stronger accumulator cover plate. Each unit is tested to verify pressures match OE specification.

For 2010-2018 trucks, the 68RFE remanufactured valve body (2010-2018) bolts in. Browse every option in our valve bodies collection. Confirm your model year first. The Sonnax tool kit page lists the SC-RFE-453 Sure Cure kit as fitting 2018 and earlier units and a separate SC-RFE-453-19 kit for 2019-later units.

Replace While You Are In There

Cost and Effort

Removing the valve body is an in-truck job through the pan. The bore repair itself is bench work: teardown, cleaning, vacuum testing, reaming in a fixture, and reassembly. That makes it best suited to a rebuilder who already owns the vacuum test stand and Sonnax tooling. For a do-it-yourselfer or a shop without that equipment, a remanufactured valve body turns a multi-step machining job into a bolt-in swap. Either way, fix the cause of the contamination and check for clutch damage, because a new valve body will not repair clutches that already burned. Find related parts in the 68RFE transmission parts collection.

Frequently Asked Questions

Can I fix 68RFE valve body bore wear by just cleaning the valve body?

No. Cleaning removes debris, but bore wear is metal that is gone. Sonnax gives the valve-to-bore clearance as .0005 to .0016 in., and once a bore wears past that, fluid leaks past the valve. The fix is reaming the bore and installing an oversized valve, or a remanufactured valve body.

How do I know if my 68RFE solenoid switch valve bore is worn?

Vacuum test it. Sonnax says vacuum loss is directly proportional to wear. Symptoms that point to this bore include codes 841, 868, 871, 988, 1775 and 1776, failsafe mode, second-gear starts with the MIL on, and burned overdrive or 4th clutches.

Which Sonnax solenoid switch valve kit fits my 68RFE?

Measure the large spool on your OE valve. Sonnax lists .453 in. valves as taking kits such as 92835-39K, 92835-22K or 92835-31K, and .420 in. valves as taking kits such as 92835-02K, 92835-18K or 92835-32K. Standard kits cover low to moderate wear; oversize kits cover excessive wear.
