Your Explorer or Mountaineer with the 5R55W is flaring between gears, slipping in lockup, or throwing a gear ratio code, and you are stuck on one question: buy a shift kit, or deal with the valve body itself? On this transmission the answer is rarely one or the other. A shift kit corrects known factory hydraulic weak points. A worn valve body has bores that leak no matter what springs you put in them. And some of the worst 5R55W complaints are not in the valve body at all. This guide walks through how to tell which problem you have and which part fixes it.

5R55W TRANSGO Shift Kit Valve Body Rebuild Kit
The part for this fix
5R55W TRANSGO Shift Kit Valve Body Rebuild Kit
$154.99 · In stock
Shop This Part →

First, Confirm You Actually Have a 5R55W

Before buying anything, identify the unit. Sonnax's 5R55 identification article lists the 5R55N in 1999-2002 Jaguar S-Type, Lincoln LS and Thunderbird, the 5R55W in 2002-2003 Explorers and Mountaineers, and the 5R55S in 2003-up Lincolns and Thunderbirds plus 2004-2005 Explorers and Mountaineers. Sonnax warns that only a few parts interchange, and that mixing solenoid components between versions can cost you reverse, TCC apply and solenoid oil pressure. The W and S also use different overdrive sun gears (24-tooth vs 38-tooth), per the same article. If you are unsure which one you have, read our 5R55S vs 5R55W vs 5R55N identification guide before ordering parts.

What a 5R55W Shift Kit Actually Does

The TransGo SK 5R55W is not just a firmer-shift kit. TransGo sells it as a "Shift Kit Valve Body Repair Kit" for the 5R55W, 5R55S and 5R55N, 1999-on. According to TransGo, it corrects or prevents:

  • Codes P1740, P1744, P0732, P0733, P0734 and P0735
  • Won't move
  • Pump noise
  • No lockup, and slips or shudders in lockup

TransGo lists the kit contents as a no-noise pump flow control valve assembly, an upgraded steel TCC/lockup valve assembly, a pump alignment tool, two EPC relief assemblies, two high-temp low-shrink direct clutch rings, and springs aimed at no/slow reverse and loss of forward gear ranges. Note that several of those parts live in the pump and on the direct clutch, not in the valve body, so follow TransGo's installation instructions to see which steps your repair calls for.

For modified vehicles, TransGo also sells the 5R55W-HD2 (fits 5R55W and 5R55S, 2002-on). On top of the standard kit, it adds reamers with oversized valves and guides for the VFS1 and VFS2 modulator valves, and TransGo states it increases intermediate and overdrive band apply pressure to shorten shift times under heavy throttle.

What a Shift Kit Cannot Fix: Worn Valve Body Bores

A shift kit replaces specific valves and springs. It does not restore a bore that has worn oval around a valve that stayed in the stock casting. On the 5R55W, Sonnax documents several of these wear points:

  • Solenoid feed limit and converter feed limit valves. Sonnax ties wear here to no lockup, delayed engagement, codes 731 through 741, overheating and front lube failure. A worn solenoid feed limit bore causes pressure problems and solenoid flooding. A worn converter feed limit bore reduces converter charge, which Sonnax says raises stall RPM and fuel consumption.
  • Fluid foaming. Sonnax notes the 5R55N, W and S are prone to foaming in the sump from excess exhaust and valve body wear. That can push fluid out the vent and throw off the fill reading.

The fix for these is bore reconditioning plus oversized valves, not a spring swap. Sonnax's 5R55W Oversized Solenoid and Converter Feed Limit Valve Kit (56947J-61K) uses hardcoat anodized aluminum valves, and Sonnax lists the F-56947J-TL61 tool kit as required to install it. Sonnax recommends vacuum testing the specified ports: if a bore will not hold the recommended minimum vacuum, or you can see the wear, it needs to be repaired. For a bore-by-bore breakdown, see 5R55W valve body common failure points explained.

The Trap: Same Codes, Different Root Cause

This is where many 5R55W repairs go wrong. P0732, P0733 and P0735 are on TransGo's list, but they are also on Sonnax's list for a problem in the case, not the valve body: servo apply pin bore wear.

Sonnax says the servo apply pin moving back and forth over time wears the overdrive and intermediate servo pin bores in the case. As that wear grows, apply oil leaks into the barrel area of the case and release oil leaks into the apply circuits, which hurts shift timing and band apply pressure. Sonnax lists the symptoms as 1-2, 2-3 and 4-5 flares, gear loss, codes 732, 733 and 735, and band lining failure. Because both servos rely on release pressure in reverse, it can also cause delayed reverse. Left alone, it can burn clutches and ruin the case.

Neither a shift kit nor a new valve body fixes a worn case bore. Sonnax's repair is the Overdrive and Intermediate Servo Pin Bore Sleeve Kit (56361J-01K). It installs wear-resistant aluminum sleeves after the bores are machined with the S-56361J-TL tool kit. If your main complaint is flares or lost 2nd, 3rd or 5th gear, read our article on 5R55S servo bore wear before you spend money on the valve body.

Diagnosis: Which Path Are You On?

  1. Scan and record every code. Lockup codes (P0741, P1740, P1744) point toward the TCC and feed limit circuits. Ratio codes (P0732-P0735) can come from the valve body or the servo pin bores.
  2. Check the fluid. Foam, fluid out the vent, or a fill level that keeps changing fit Sonnax's description of wear-related exhaust and foaming.
  3. Note when it happens. Flares on specific upshifts plus delayed reverse point to the servo pin bores. No lockup, overheating and delayed engagement point to the feed limit valves.
  4. Vacuum test the valve body at the ports Sonnax specifies before deciding whether the casting can be saved.

So Which One Do You Need?

5R55W TransGo shift kit valve body rebuild kit
5R55W TransGo Shift Kit Valve Body Rebuild Kit
  • Stock or near-stock vehicle, valve body passes vacuum testing, lockup or engagement complaints: the 5R55W TransGo shift kit covers TransGo's listed codes and corrects the factory weak points while the valve body is apart.
  • Valve body fails vacuum testing at the feed limit bores: the shift kit alone will not seal those leaks. Add the oversized feed limit valve kit and its tooling, or replace the valve body with a unit that has already been corrected.
  • Performance use: TransGo's HD2 adds VFS modulator valve correction and higher band apply pressure for heavy-throttle shifts.
  • Flares, gear loss, delayed reverse, band failure: check the servo pin bores in the case first. No valve body part fixes a worn case.

Replace While You Are In There

With the pan down and the valve body out, replace the filter and pan gasket at the same time. If you are going deeper, the 5R55W transmission parts collection has solenoid packs, servo piston kits, bands and overhaul gasket sets. Browse all makes in our shift kits collection.

Cost and Effort

A shift kit is the lowest-cost fix, but it still means removing and fully disassembling the valve body, and possibly working on the pump and direct clutch, depending on which parts of the kit you install. Bore repair with Sonnax oversized valves adds precision reaming with dedicated tooling, so plan for a clean bench and careful measuring, or send the valve body to a shop that does this work. A servo pin bore sleeve repair is a case machining job. It is the most work of the three, but Sonnax presents it as a way to save a case instead of replacing it.

Frequently Asked Questions

Will a shift kit fix 5R55W slipping?

It depends on the cause. TransGo lists lockup slip and shudder plus codes P0732-P0735 among the problems its SK 5R55W corrects or prevents. But Sonnax ties the same ratio codes and upshift flares to servo apply pin bore wear in the case, which a shift kit cannot repair.

Does the 5R55W shift kit fit the 5R55S and 5R55N?

TransGo lists the SK 5R55W for the 5R55W, 5R55S and 5R55N, 1999-on. The HD2 performance kit is listed for the 5R55W and 5R55S, 2002-on only. Sonnax warns that most other internal parts do not interchange between versions.

How do I know if my 5R55W valve body is too worn for a shift kit?

Vacuum test the bores. Sonnax recommends testing the specified ports: a bore that will not hold the recommended minimum vacuum, or wear you can see, calls for bore reconditioning with oversized valves, not just a kit.
