If you landed here comparing a GM 10L80 to a Chrysler 62TE, the most useful thing to know up front is that these two are not competing choices. They are opposite ends of the automatic transmission world: one is a ten-speed longitudinal unit bolted behind a V8 in a rear-drive truck, the other is a six-speed transverse transaxle sitting sideways in a front-drive minivan. They do not interchange, and no adapter makes them interchange.

Parts for your 10L80

See all 10L80 rebuild kits

Get the parts for this repair
Shop 10L80 Parts →

What people actually need is usually one of three things: confirming which unit they have, understanding why one is rated so much stronger, or deciding whether the unit they have is worth rebuilding. This article covers all three.

The fast identification test

You almost never need a tag number to tell these apart. Look at how the engine sits:

  • Engine front-to-back, driveshaft running to a rear axle — that is the 10L80. Full-size trucks and SUVs, plus the Camaro.
  • Engine sideways, halfshafts to the front wheels, no driveshaft — that is the 62TE. Minivans, mid-size sedans, and crossovers.

Per Wikipedia's Ford-GM 10-speed entry, the 10L80 went into production in 2017 at GM's Romulus, Michigan powertrain plant, with Silao, Mexico adding output in 2018. Applications include the Chevrolet Silverado 1500, Chevrolet Tahoe, Cadillac Escalade, and the 2019-2024 Camaro SS.

The 62TE ran 2006 through 2020 per GearboxList, across the Chrysler Pacifica, Sebring, Town & Country and Grand Voyager, the Dodge Avenger, Journey and Grand Caravan, and the Volkswagen Routan.

Gearing and ratio spread

This is where the ten-speed earns its complexity. DieselHub's 10R80/10L80 specification page lists the 10L80 forward ratios as 4.70, 2.99, 2.15, 1.80, 1.52, 1.28, 1.00, 0.85, 0.69, and 0.64:1. Wikipedia puts the total ratio span at 7.386 with an average step of just 1.249 between gears.

GearboxList gives the 62TE ratios as 4.127, 2.842, 2.283, 1.452, 1.000, and 0.690:1, running through a 3.246 final drive, with reverse at 3.214.

Two things fall out of those numbers. The 10L80's steps between gears are far tighter, which is why it holds the engine in a narrow band and shifts constantly. And it carries two ratios past direct drive below the 62TE's single 0.690 overdrive, which is what drops highway engine speed on a truck otherwise geared for towing.

Strength: the gap is not close

Wikipedia lists the 10L80 at a maximum input torque rating of 900 N-m, or 664 lb-ft, while DieselHub cites roughly 590 lb-ft as the nominal figure. GearboxList rates the 62TE at up to 400 N-m, which is about 295 lb-ft.

DieselHub also lists the 10L80 at roughly 230 lbs dry with an aluminum case and a 260 mm torque converter. The 62TE, as a transverse transaxle, packages the differential and final drive inside the same housing, which is a large part of why its torque ceiling sits where it does. It is not a weak design; it is simply engineered for a V6 driving the front wheels, not a V8 pulling a trailer.

Architecture, and why the 62TE fails where it does

The 10L80 uses four gearsets, two brakes, and three clutches per Wikipedia — a clean-sheet longitudinal design.

The 62TE is built around a compounder planetary section, and that compounder is the unit's signature failure point. Gears Magazine's 62TE rebuild article is blunt about it: completely disassemble the compounder even on low-mileage units, and inspect the bearings, splines, ring lands, drums, and snap ring grooves. That article identifies DTCs P0732 and P0735 as pointing to probable compounder problems, and recommends monitoring countershaft speed sensor data during diagnosis. It also calls out the updated low clutch drum assembly with locking rings as the durability fix, and lists Mopar complete compounder assembly part number 05078815AD.

The other classic 62TE complaint is a stumble or shudder as the vehicle comes to a stop. Gears Magazine attributes that to a mechanically faulty torque converter clutch solenoid, and notes it can be serviced separately without pulling the transmission — turning a transaxle-out job into an in-vehicle repair.

62TE shift solenoid pack with transmission filter and pan gasket
The 62TE solenoid pack, filter, and pan gasket. Shop the 62TE Shift Solenoid Kit 2007-Up.

Diagnosis order before you condemn anything

For a 62TE with no movement in drive, Gears Magazine recommends ruling out the cheap and the mechanical before assuming the torque converter has failed. Check fluid level, then a restricted sump filter, pump gear damage, stripped axles or differential damage, stripped transfer gear splines, and a dislodged check ball in the case line port near the pan. If that check ball has blown out, the article specifically says not to reinstall it: tap the hole with 1/8 inch pipe thread and install a pipe plug with permanent thread locker.

For the 10L80, there is a documented safety issue worth checking before you spend money. NHTSA campaign 24V797000 covers certain 2020-2022 Chevrolet Silverado and GMC Sierra 1500/2500/3500, plus 2021 Cadillac Escalade and Escalade ESV, Chevrolet Tahoe and Suburban, and GMC Yukon and Yukon XL, all with diesel engines. Per the NHTSA record, the transmission control valve may fail and cause the rear wheels to lock up. The remedy is new transmission control module software at no charge, plus a special coverage program covering transmission repair where the remedy software identifies a defective control valve. A follow-up campaign, 26V083000, addresses vehicles repaired incorrectly under the original recall. Run your VIN before you pay for anything.

The fix: what to buy for each

On the 62TE, the repair path depends on the symptom. Harsh shifts, slipping, and limp mode usually route to the solenoid pack and valve body side; our write-up on 62TE valve body symptoms walks that diagnosis. Ratio codes and compounder noise mean the unit is coming out, and at that point a full 62TE Master Transmission Rebuild Kit for 2008-2014 is the sane approach, because the guidance to tear the compounder down completely means you are already that far in.

On the 10L80, clutch and steel plate wear from heat and towing duty is the common rebuild driver. A 10L80 Steel Clutch Plate Kit for 18-Up covers the steel side of that job. Browse the full clutch pack and friction plate collection or the transmission solenoid collection to match the rest of the build.

Replace while you are in there

  • 62TE: filter and pan gasket, full seal and o-ring set, the TCC solenoid if the stumble complaint was present, the updated low clutch drum assembly, and the shift shaft seal area. If the compounder showed any spline or snap ring groove damage, replace rather than clean up.
  • 10L80: frictions and steels as a matched set, filter, pan gasket, and fresh fluid to the correct specification. Verify the recall status and control module calibration level before final road test.
  • Both: flush or replace the cooler and lines. Reinstalling a fresh unit onto a contaminated cooler is the fastest way to do the job twice.

Fluid, and a note on conflicting figures

GearboxList specifies Mopar ATF+4 to MS-9602 for the 62TE, with a capacity of 8.5 liters.

The 10L80 is fussier, and the published numbers do not agree. DieselHub lists DEXRON ULV ATF for GM applications at approximately 13 U.S. quarts, with a normal operating temperature of 206-215 degrees F. Advance Adapters' 10L80 documentation instead gives 11.5 to 12 quarts and recommends fluid changes every 97,500 miles under normal conditions or 45,000 miles for severe use. Verify both against the service information for your exact year and application, and do not substitute a conventional ATF where an ultra-low-viscosity fluid is specified.

Effort and difficulty

Neither is a first-timer job, but they are not equally difficult. A 62TE solenoid pack and filter service is an in-vehicle repair on most applications and lands in the low single-digit hour range for a competent DIYer with the vehicle safely supported. A full 62TE rebuild means pulling the transaxle, separating the case, and completely disassembling the compounder, which is a multi-day job for anyone not doing them routinely, and it requires the post-rebuild relearn. Gears Magazine describes that relearn as a calibration cycle performed at a fluid temperature around 90 degrees F using drive and neutral cycling.

The 10L80 is a heavy, tightly-toleranced ten-speed with extensive electronic control, and removal alone requires proper support equipment for a roughly 230 lb unit in a truck chassis. Most owners are better served buying the internal parts and having a shop with the ten-speed specific tooling and calibration access do the assembly.

FAQ

Can a 62TE be swapped for a 10L80?

No. The 62TE is a transverse front-wheel-drive transaxle with the final drive and differential built into the housing; the 10L80 is a longitudinal rear-wheel-drive transmission that requires a driveshaft and a separate rear axle. Swapping one for the other means changing the vehicle's entire drivetrain layout.

What do P0732 and P0735 mean on a 62TE?

Gears Magazine identifies both as gear ratio codes that indicate probable compounder problems. Their guidance is to monitor countershaft speed sensor data as part of that diagnosis rather than treating the code as a standalone verdict.

Is the 10L80 the same as the Ford 10R80?

They are the same joint-venture design with company-specific calibration. DieselHub notes the transmissions share hardware but carry unique electronics integrated into each company's respective powertrain. Wikipedia adds that the ten-speed was designed by Ford while GM designed the nine-speed in the same partnership. For a deeper GM-side comparison, see our 8L90 vs 10L80 breakdown.
