Two numbers decide whether a GM 10L80 service goes right or wrong: what fluid goes in, and how much. Get either one wrong and the transmission tells you within a few hundred miles — shudder, harsh engagement, high transmission temperature, or fluid venting out the breather. This is one of the few transmissions where a single quart of error is a real failure mode.

Parts for your 10L80

See all 10L80 rebuild kits

Get the parts for this repair
Shop 10L80 Parts →

Here are the published numbers, straight from GM's own capacity chart, plus the level-check procedure that actually sets the level and the parts to have on the bench before you start.

What fluid does a 10L80 take?

DEXRON ULV. Not DEXRON VI, not DEXRON HP, not a universal ATF that lists ten specs on the bottle.

GM's own 2025 Transmission Capacities & Fluids chart, published through GM TechLink, lists DEXRON ULV for every 10L80 application in the U.S. and Canada — Silverado 1500, Sierra 1500, Tahoe, Suburban, Yukon and Yukon XL, Escalade, Cadillac CT4 and CT5 — across every RPO the chart carries for the unit (MQB, MQC, MHT, MI2, MHS and MHU). The same chart specifies DEXRON ULV for the 10L60, 10L90 and the heavy-duty 10L1000, while the 8L80 and 8L90 alongside them get DEXRON HP and the older 6L90 gets DEXRON VI. Those are three genuinely different fluids in the same truck lineup, and the parts counter will hand you the wrong one if you ask for "GM transmission fluid."

ULV stands for ultra low viscosity. That is the entire point of the specification. GM's 10-speed uses tighter clutch clearances and a lot more clutch elements than a 6-speed, and the fluid is formulated thin specifically to avoid unwanted clutch drag and bind-up. Pouring in a thicker DEXRON VI or HP does not "protect" the unit — it adds drag, and drag makes heat.

ACDelco is the OEM supplier for the specification; the quart bottle sold for the 2020-2026 10L80 and 10L1000 applications carries ACDelco part number 19352619. Whatever brand you buy, the bottle needs to say DEXRON ULV.

10L80 fluid capacity: the numbers that matter

Three different figures get quoted for this transmission and people mix them up constantly. They are not interchangeable.

Pan drop and filter change: 7.7 liters / 8.1 quarts

This is GM's own published fluid change capacity in the 2025 TechLink chart, and it is identical across every 10L80 RPO listed: 7.7 L (8.1 qt). Not a range, not "approximately." That is the service-fill figure for a normal pan-and-filter job where the converter and cooler stay full.

For contrast, the same chart lists the 10L1000 in the 2500/3500 HD trucks at 13.6 L (14.4 qt), so do not carry an HD number over to a 1500.

Full overhaul: about 11.6 quarts

DmaxStore's 10L80 service listing for the 2020-2025 LM2/LZ0 applications gives 11.57 quarts for a transmission overhaul and roughly 12 quarts for the complete transmission system including converter and cooler circuit. Treat those as planning figures. The exact amount depends on how much fluid stayed behind in the converter and cooler, which is why a full-fill number is always approximate and the level check is not.

The mistake this causes

The classic error is pouring an overhaul-sized fill into a pan-drop service. Sonnax is blunt about the consequence on the closely related Ford 10-speed family: as little as 1 quart (1 L) overfilled will cause both overheating and venting. Their explanation of how it happens is worth memorizing — the unit gets filled cold on the lift to the top level, which lands about a quart over the full mark once it reaches operating temperature. There is no reason to think the GM 10-speed is more forgiving.

How the level is actually set on a 10L80

There is no dipstick. On these transmissions the level is set by a standpipe and a fill/level check plug, and the fluid temperature window is part of the procedure, not a suggestion.

  1. Vehicle level. On a lift with all four points even, or on flat ground. The level is a puddle height; a slope moves it.
  2. Fill through the correct port with a pump. On 2018-2020 units the filling and level checking is done through the port in the bottom of the pan rather than the side plugs, using an adapter so fluid can be pumped up into the pan. Later applications use a side fill plug with the same pump-tool approach. The internal standpipe at that port is what establishes correct level — that plug is a fill and level-check plug, not a drain plug.
  3. Bring the fluid into the temperature window. Published guidance for the 10L80 puts the check at a transmission fluid temperature of 75°C to 80°C (167°F to 176°F), verified on a scan tool. Sonnax's window for the Ford 10-speed sibling is higher, 91°C to 102°C (196°F to 216°F), which is a good reminder that these windows are unit-specific — confirm the figure for your exact model year in service information rather than assuming.
  4. Cycle the ranges, then settle. Shift through the gear ranges with the brake applied so the clutch circuits fill, return to park, and let it settle.
  5. Let the excess run out. Pull the adapter and let fluid drain until it stops. When it stops flowing, the level is correct. Reinstall the plug.

If you cannot get the transmission into the temperature window and hold it there, stop. A cold check on a 10L80 will leave you overfilled, and overfilled is the condition that vents fluid and cooks it.

The parts to have before you start

The filter is the reason you dropped the pan. Do not reuse it, and do not reuse the filter bolts — they are torque-to-yield fasteners, published at 44 in-lbs plus a 128-degree rotation, which means they stretch by design and are single-use.

10L80 transmission filter for 2020-2024 GM 10-speed
10L80 Transmission Filter 20-24 — the pan does not come off without one.

Replace while you are in there

  • Filter and pan gasket. Both, every time.
  • Filter bolts. Torque-to-yield, single use.
  • Fill and level-check plug seals if they look flattened.
  • Enough DEXRON ULV to finish the job. Buy 9 or 10 quarts for a pan service so you are not stopping at 8.1 with the plug open, and more if you are refilling an overhauled unit.
  • A cooler inspection. If the fluid you drained was dark or smelled burnt, the cooler is holding the same debris and will feed it straight back into a fresh build.

Shop the transmission filter collection for the correct 10L80 filter and pan set. If the pan told you a worse story than routine service — clutch material, metal on the magnet — you are looking at a rebuild kit rather than a fluid change, and the fluid was a symptom.

Cost and effort framing

Fluid and a filter is the cheapest thing you will ever do to a 10L80, and the temperature-window check is the part that makes it worth doing at all. The special-tool cost is real but modest: a fluid pump with the right adapter, and a scan tool or app that reads transmission fluid temperature live. Without the temperature readout you are guessing, and guessing on this unit is how people end up chasing a shudder they created.

Budget an afternoon. The pan is held on by 10 mm bolts with no drain plug, so plan for a controlled mess, and plan for the refill to take longer than the drain because it is pumped in from underneath rather than poured in from above.

For the full step-by-step service including the Ford 10R80 differences, see our 10L80 and 10R80 fluid change guide. If the reason you are reading this is a transmission that runs hot, read our 10L80 overheating diagnosis order before you add anything, because an overfill is one of the first things it rules out.

Frequently Asked Questions

Can I use DEXRON VI or DEXRON HP in a 10L80?

No. GM's 2025 transmission capacities and fluids chart specifies DEXRON ULV for every 10L80 application. DEXRON HP is what the 8L80 and 8L90 take and DEXRON VI is what the 6L90 takes, and all three appear in the same truck lineup. ULV is an ultra low viscosity fluid chosen deliberately to keep the 10-speed's clutches from dragging; a thicker fluid adds drag and heat.

How many quarts does a 10L80 pan drop and filter change take?

7.7 liters, or 8.1 quarts, per GM's published fluid change capacity, and that figure is the same for every 10L80 RPO listed in the chart. A full overhaul is a different number entirely, around 11.6 quarts. Never use the overhaul figure for a pan service.

What temperature should a 10L80 be when I check the level?

Published guidance for the 10L80 puts the check at 75°C to 80°C (167°F to 176°F) transmission fluid temperature, read on a scan tool. Confirm the window for your exact model year in service information — the Ford 10-speed sibling uses a much higher band, so these numbers do not carry across units.
